• Production Capacity：50000PCS,Year
• HS Code：84379000

Model

MNMLs40

MNMLs46

MNMLs51

Capacity (t/h)

4~6

6~10

10~15

Power (kw)

45

55

55/75

Air Pressure (Pa)

100-150

150-200

150-200

Size (L*W*H) mm

1450×1150×2100

1600×1300×2200

2100×1400×2400

Weight (kg)

1500

1700

1900

Working Principle

Brown rice is divided equally by distributor when feed to machine, and then enters the top of whitening chamber, and is conveyed by screw propeller from top to bottom to the clearance between emery roll and screen. Here, brown rice moves downwards spirally along the emery roll surface, and the bran is separated by fractioned action between the surface of emery roll rotating at a certain linear speed and the rice blade. In addition, the rice grains can be milled and whitened by frictional action between the screen plate and rice grains as well as rice grains.

Negative pressure generated by the bran suction fan forces the air around the bottom of the main shaft to enter the hollow shaft and then pass through the materials from inside to outside, thus the materials are cooled and the temperature of rice is reduced. In addition, the bran is forced to discharge from the screen apertures rapidly and sucked out by the bran suction fan.

Packing And Delivery

For safety transportation purpose, we use standard exporting packing for all the machines. Packing method such as wood box/tray, steel box/tray etc, to ensure the machine will be reached to you safely.

Our Service

[Consulting Service] Our consultant provides you with pre-sales expertise consulting services, system evaluation, providing the best engineering solution

[Engineering Service] Set up special project team of technical, installation and sales for you. to design, install and commissioning a complete set of equipments, whole process tracking service.

[Training Service] Our experts in technology and management provide you long term production, operation, management, maintenance and other professional skills training, to help you train operation, technology, management personnel.

[Spare Part Service] We provides high-quality and reliable original accessories. And the service centers also keep store of a certain number of common accessories to meet the demand of rapid supply.

[Site service] Our service engineer goes deep into your site to solve practical problems. Conduct on-site training on the use of products and seek for improvement of a new way of thinking and method to reduce cost and increase efficiency.

FAQ

1. What emery # available for emery whitener?

The emery # available at 24#-30#-36#-46#

2. What material you use for rice whitener screen?

It is high strength stainless steel with special heat treatment, long service lift.

3. How can we adjust milling pressure?

Resistance plate can be adjusted without stop the machine, the pressure in whitening chamber can be changed by adjusting the gap between resistance plate and emery roll.

4. What is the guarantee of your machine?

We guarantee the delivered equipments for a period ("warranty period") of 12 months.

5. What payment term you can do with us?

Our expect payment term: T/T, irrevocable L/C, D/P
