Wedo Non Sparking Aluminium Bronze Hook Wrench with Pin Bam/FM/GS
SHANDONG JUSU CLOUDS PLASTICS CO., LTD.- Type：Hook Spanner
- Material：Aluminium Bronze
- Standard：Metric
- Brand：WEDO
- Surface Treatment：Polishing
- Size：Common
Base Info
- Model NO.：AL173C
- Feature：Anti-Explosion
- Working Mode：Manual
- Folded：Unfolded
- Handle Color：Pure
- Application Age：Adult
- Certificate：Bam,FM,GS
- Transport Package：Plastic Bag,Box,Carton,Pallet
- Specification：from 30-32 to 110-115mm
- Trademark：WEDO
- Origin：China
- HS Code：8204110000
- Production Capacity：50000PCS,Year
Description
Basic Info.
Model NO. AL173C Feature Anti-Explosion Working Mode Manual Folded Unfolded Handle Color Pure Application Age Adult Certificate Bam/FM/GS Transport Package Plastic Bag/Box/Carton/Pallet Specification from 30-32 to 110-115mm Trademark WEDO Origin China HS Code 8204110000 Production Capacity 50000PCS/YearProduct Description
| ITEM CODE | SIZE |
| AL173C-1002 | 30-32mm |
| AL173C-1004 | 34-36mm |
| AL173C-1006 | 40-42mm |
| AL173C-1008 | 45-50mm |
| AL173C-1010 | 52-55mm |
| AL173C-1012 | 58-62mm |
| AL173C-1014 | 68-75mm |
| AL173C-1016 | 80-90mm |
| AL173C-1018 | 95-100mm |
| AL173C-1020 | 110-115mm |
Above item no. is only for Aluminium Bronze material, Besides Aluminium Bronze, WEDO also supply in Beryllium Copper, below are differences of two material.
Aluminum Bronze Non-sparking Tools
1. Appropriate for operation with ethylene concentration below 7.8%
2. Surface Color: Silver Yellow
3. Micro-magnetic
4. Hardness: 20-30 HRC
5. Tensile Strength: 782N/mm²-989N/mm²
6. Elasticity Limit: 450N/mm²-550N/mm²
7. Extensibility: δ≥5%
Beryllium Copper Non-sparking Tools
1. Appropriate for operation with hydrogen concentration below 21%,
2. Surface Color:Golden Yellow
3. Non-magnetic
4. Hardness: 30-40 HRC
5. Tensile Strength: 1117N/mm²-1326N/mm²
6. Elasticity Limit: 840N/mm²-880N/mm²
7. Extensibility: δ≤1.0%
To ensure the explosion-proof performance, after the raw materials are melt with scientific ratio, QC personnel will take sample piece to do drop weight and friction test according to GB/T 10686-2013 standard. The test is conducted under the highest level ExIIC, hydrogen concentration 21%. Only if the samples are tested qualified can the next step of production be carried out.
The explosion-proof performance of WEDO non-sparking tools is guaranteed for lifetime.
