Good Quality Fully Automatic HDPE Wrap Film Rewinding Machine
Ningbo CCMS Industrial Co., Ltd.Base Info
Description
Basic Info.
Model NO. PPD-HDPEW600 Speed 2000rpm/Min Power 5kw Volatge 220/380/415V,3pH Transport Package Plywood Case Specification CE, SGS, ROHS Trademark PPD Origin China(Mainland) HS Code 84778000 Production Capacity 10units/MonthProduct Description
Description:
Good Quality Fully Automatic HDPE Wrap Film Rewinding Machine is high speed automatic operation by PLC program,HMI touch screen.
Good Quality Fully Automatic HDPE Wrap Film Rewinding Machine is specially designed for high speed automatic rewind the jumbo roll of HDPE film into smaller diameter roll.
The machine is built a unique system for meeting the rewind the non-sticky HDPE film,it avoids the disperse the end film from the rewind roll.
Machine completes with ergnomics design for fully automatic operation.User friendly,high speed.
Main Specs:
| Material | HDPE/LDPE/stretch/cling film |
| Max width of jumbo roll | 600mm |
| Max outer dia of jumbo roll | 600mm |
| Inner dia of jumbo roll: | 76m |
| Rewind roll width | 200-600mmm |
| Rewind roll inner dia | 25-76mmm |
| Rewind roll outer dia | max300mm |
| Speed | 2000RPM/Min |
| Power | 5KW |
| Air supply | 0.3Mpa |
| Voltage | 220/380/415v,3PH |
