High Speed Omm50 Orbital Hydraulic Motor Replace Danfoss Hydromotor
Guangzhou Cospack Packaging Technology Co., Ltd.- Speed：High Speed
- Type：Hydraulic Power Units
- Displacement(Cc/Rev)：50
- Continuous Max Speed(Rpm)：400
- Continuous Max Torque(N.M)：46
- Max Pressure(MPa)：10
Base Info
- Model NO.：Omm50
- Hole Middle Distance：80mm
- Cylinde Parallel Shaft Size：16mm
- Flange：Standard 2 Hole Diamond Flange
- Ports and Drain Port：G3,8, G1,8
- Material：Rust-Proof Cast Iron
- Warranty：One Year
- Flow Control Valve：Hydraulic Motor
- Pressure Control Valve：Hydraulic Motor
- Hydraulic Control Unit：Hydraulic Motor
- Hydraulic Motor：Omm50hydraulic Motor
- Hydraulic Actuator：Hydraulic Motor
- Transport Package：Sale Packing Contians Carton or Wood Case
- Specification：CE
- Trademark：Blince
- Origin：Guangdong Province, China (Mainland)
- HS Code：8412291000
- Production Capacity：3000 Units Per,Month
Description
TypeOMM
8 OMM
12.5 OMM
20 OMM
32 OMM
40 OMM
50 Geometric displacement 8.2 12.9 19.9 31.6 39.8 50.3 Max.speed (rpm) cont. 1950 1550 1000 630 500 400 int. 2450 1940 1250 800 630 500 Max.torque(N.m) cont. 11 16 25 40 45 46 int. 15 23 35 57 70 88 Max.output(KW) cont. 1.8 2.4 2.4 2.4 2.2 1.8 Int. 2.6 3.2 3.2 3.2 3.2 3.2 Max.pressure
Drop (Mpa)
cont. 10 10 10 10 9 7 int. 14 14 14 14 14 14 Max.flow(L/min) cont. 16 20 20 20 20 20 int. 20 25 25 25 25 25 Weight(kg) 1.9 2 2.1 2.2 2.3 2.4
Blince profssion supply all series hydraulic motor like:
OMM/OMP/OMPH/OMR/OMRS/OZ/OK/OMH/OMSY/OMT/OMV hydraulic orbit motor, hydraulic pump like ( PV2R series / V V series / SQP series ) vane pumps. If you are interested in any our blince hydraulic motor pls contact me. Thanks! !
8
12.5
20
32
40
50
Drop (Mpa)
Blince profssion supply all series hydraulic motor like:
OMM/OMP/OMPH/OMR/OMRS/OZ/OK/OMH/OMSY/OMT/OMV hydraulic orbit motor, hydraulic pump like ( PV2R series / V V series / SQP series ) vane pumps. If you are interested in any our blince hydraulic motor pls contact me. Thanks! !
