Shoes Woman Laser Marking Engraving Cutting Machine for Wood Leather
Xiamen Teyate Aluminum Co., Ltd.- Laser Visibility：Invisible
- Applicable Material：Nonmetal
- Cooling System：Air Cooling
- Technical Class：Pulse Laser
- Laser Wavelength：CO2 Laser
- Laser Classification：Gaseous Laser
Base Info
- Model NO.：CKD-CMLA-20,30,50,60,70
- Type：CO2 Laser Marking Machine
- Marking Method：Scanning Marking
- Marking Material：Ceramics, PVC, Wood, Paper and Other Nonmetal
- Function：Mark, Cut, Engrave
- Shipping Date：3-5 Work Days After Payment
- Marking Scope：100*100,150*150,200*200mm
- Transport Package：Wooden Box
- Specification：CE passed, Europe, Asia, America Standard
- Trademark：CKD LASER
- Origin：Shenzhen, China
- HS Code：8456100090
- Production Capacity：200 Set,Month
Description
laser source30W/40/70 Optional marking scope recommend CKD-CMLA-30/40 100*100mm big marking scope weaken laser power, there are suitable recommend for you. CKD-CMLA-70 Optional: 100*100/150*150/200*200mm Computer Window 7/10 Computer language: English as basic, you can choose your language after receiving. Marking Software EzCad2 Language: English, Chinese, Korean, Japanese Control Board BJJCZ Original newest version Rotary chuck diameter: 50mm Optional part, for jewelry marking Optional chuck diameter: 80mm Optional part, for tuber or column marking chuck diameter: 100mm Optional part, for bigger column, cup, bottle, etc. Foot switch with standard attchment, every type with Focusing tool with help you find right focus easily, standard attchment, every type with
PARAMETER
ADVANTAGE
* Multi-functions: carving/engraving/marking/cutting.
* Series number jumping mark, photo amrk, vector logo mark, etc.
* Anti-interference, stability.
* High accuracy, long time use without correction.
* Compact structure, all-in-one machine, easy lean and operation.
CONTACT US / ONLINE SERVICE
Please send your inquiry or place order with certain configuration directly by following dialog box, we will reply you immediately.
Please tell us your application if you need configuration suggestion.
PARAMETER
| Parameters | Unit | Data | Data |
| Type | CKD-CMLA-30/40 | CKD-CMLA-70 | |
| Power | W | 30/40 | 70 |
| Laser Type | CO2 laser | CO2 Laser | |
| Central Wavelength | um | 10.6 | 10.6 |
| Optional Marking Area | mm | 75*75/140*140 | 75*75/140*140/175*175/210*210 |
| Marking Speed | mm/s | ≤7000 | ≤7000 |
| Software | EzCad | EzCad | |
| Life-span of Fiber Laser Module | hrs | 45000 | 45000 |
| System Operation Environment | Windows 7/8/10 | Windows 7/8/10 | |
| Cooling Mode | Air cooling | Air cooling | |
| Temperature of Operation Environment | ºC | 15~35 | 15~35 |
| Power Source Requirement | 90-240V/50-60Hz/2KVA | 90-240V/50-60Hz/2KVA | |
| Computer | With | With | |
| Dimension (L*W*H) | mm | 980*615*1480 | 980*615*1480 |
ADVANTAGE
* Multi-functions: carving/engraving/marking/cutting.
* Series number jumping mark, photo amrk, vector logo mark, etc.
* Anti-interference, stability.
* High accuracy, long time use without correction.
* Compact structure, all-in-one machine, easy lean and operation.
