700mm Diamond Saw Blade for Cutting Quartz Jade Granite
QINGDAO YOUNGSTAR PLASTICS CO., LTD.- Application：for Cutting Various Quartz
- Slot：Narrow U Slot
- Welding Method：High Frequency Silver Brazed
- Size：700mm
- Segment：40*5.4*9mm
- Working Condition：Wet Use Only
Base Info
- Model NO.：DS700
- Machinery：Laser Infrared Ray Cutting Machine
- Quality Available：Premium, Medium, Standard
- Kind：Stone Sawing Machine
- Manufacturing Arts：Sinter
- Usage：Stone Cutting
- Transport Package：Paper Cartons and Plywood Cartons
- Specification：200-400mm
- Trademark：WANSHIN
- Origin：Quanzhou
- HS Code：82023100
- Production Capacity：1000PCS,Month
Description
Basic Info.
Model NO. DS700 Machinery Laser Infrared Ray Cutting Machine Quality Available Premium, Medium, Standard Kind Stone Sawing Machine Manufacturing Arts Sinter Usage Stone Cutting Transport Package Paper Cartons and Plywood Cartons Specification 200-400mm Trademark WANSHIN Origin Quanzhou HS Code 82023100 Production Capacity 1000PCS/MonthProduct Description
Diamond Saw Blade for cutting QuartzFeature:
Fast cutting speed, straight&smooth edge, no edge chipping problem
Notes during the cutting process:
1. During the installation period, please calibrate the flange plate, regulate the axis
2. Better to use laser infrared ray cutting machine, then the effects of cutting will be perfect
3. Please use water when cutting the ceramics, it can't be used in dry condition
4. Please keep low speed when just beginning, ajust the speed slowly till stable
5. We can adopt unique formula for different hardness quartz.
| Diameter (mm) | Inner hole (mm) | Segment length (mm) | Segment thickness (mm) | Segment height (mm) | Segment No. (PCS) |
| 125 | 20 | 40 | 1.8 | 10 | 9 |
| 150 | 25.4 | 40 | 1.8 | 8 | 11 |
| 180 | 25.4 | 40 | 2.3 | 8 | 12 |
| 200 | 60 | 44/42 | 2.4 | 7.5 | 17 |
| 250 | 50/60 | 46/43 | 2.2/2.4 | 7.5 | 17 |
| 300 | 50/60 | 43/41 | 2.2/2.4/2.6 | 7.5 | 21 |
| 350 | 50/60 | 43/41 | 2.6 | 7.5 | 25 |
| 400 | 50/60 | 43/41 | 3.1 | 7.5 | 28 |
