Stainless Steel Jacketed Mixing Cooking Pot with Agitator and Scraper Price
NINGBO HAISHU JUDIN PACKING PRODUCTS CO., LTD.- After-sales Service:Online Service
- Warranty:1 Year ,2year
- Usage:Biscuit, Cake, Pizza, Bread, Food Industry
- Power Source:Electric
- Timing Device:With Timing Device
- Type:Cooking Kettle
Base Info
- Model NO.:KQ Series
- Voltage:220V,380V,440V
- Customized:Customized
- Name:Stainless Steel Jacketed Mixing Cooking Pot with
- Material:Sanitary Stainless Steel 304 , 316
- Function:Heating and Mixing
- Capacity:50L to 1000L
- Jam Cooking Kettle:Kettle with Scrapper Agitator
- Industry Jacket Kettle:Cooking , Pasteurizing and Mixing Liquid
- Heating Source:Electric Heating Kettle, Steam Heating Kett
- Mixer:Scrapper Mixer, Customized
- Kettle Heating Source:by Steam,Electricity,Gas
- Kettle Type:Tilting, Vertical ,Fixed
- Motor:Siemens ,ABB ,China Brand
- Packing:Wooden Box
- Delivery:10 to 15 Days
- Working Life:More Than 10 Years
- OEM:Yes
- Transport Package:Standard Export Wooden Box
- Specification:ISO
- Trademark:KQ
- Origin:Shanghai, China
- HS Code:8479820090
- Production Capacity:2000set ,Year
Description
Product Name:Stainless steel jacket kettleDescription:Designed according to 3A standard, widely used for transfer viscous media in the food-processing, cosemtics and pharmaceutical industriesConstruction: vertical jacketed kettle,tilting jacketed kettleHeating mothedBy electricity (oils or water), by steam, by gasMaterial:SS304/SS316L/1.4301/1.4404Capacity:50L-1000LAgitator Type:With PTFE scraperMechanical seal:SIC/SiC/EPDM(Standard)Motor power:0.55kw, 1.1kw, 1.5kw, 2.2kw, 3kw, 7.5KWSealing option:Sanitary single mechanical seal/Double mechanical seal with cooling systemVoltage:220V, 380V,415VMotor:ABB, LOCAL,50hz/ 60hzSurface treatment:Inner polished and outside polishedAvailably connection:Clamp, Thread Butt weld, FlangeAvailably standard:DIN, SMS, 3A, RJT, ISO/IDFOperated:ElecticApplication scope: Dairy, food, beverage, pharmacy, cosmetic, etcPackaging Details:Plywood case or customerized. Or as per the request of customersDelivery details:Usually within 20 days after receiving T/T down payment


Stainless steel double-layered boiler/kettle ,used for heating, mixing fruit jam and processing meat, food, Candy, pharmacy, dairy , liquor, cake, drink, candied fruit, etc
JACKET Kettle PART
Capacity: 300L TO 1000L
Material: SS304
Heating by Electric (380V, 50HZ)
* Type: with Jacketed wall
* Internal shell thickness: 3 mm
* Jacket thickness: 3 mm
stainless steel electric/steam/gas heating jacket kettle
KQ100
KQ150
KQ200
KQ300
KQ400
YT500
Capacity L
100
150
200
300
400
500
Jacketed pressure
Mpa
< 0.2
Evaporation capacity
kg/h
40
50
65
75
100
150
Heat area
m 2
0.45
0.76
1.0
1.15
1.44
1.90
Energy consumption
kg/h
44
55
72
90
110
165
N.W.
kg
190
210
230
320
360
485
LxWxH
mm
800X650X830
1350X650X1100
1400X700X1100
1450X800X1110
1500X850X1140
1600X900X1150
