Model

HW453

Engine

Yuchai YC6L260-H300 191kW@2,150rpm
Yuchai YC6L260-H300 191 kW @ 2,150 rpm

Hole Range

90-138 mm

Drill Pipe Storage

7+1

Drill Pipe Diameter

76X3,000 mm

DTH Hammer

4"

Rotation Torque ( Max.)

2,800 N.m

F.A.D

16 m3/min

Working Pressure ( Max.)

17 bar

Pull Up Force ( Max.)

31 kN

Tramming Speed ( Max.)

3 km/h (High Speed)
2 km/h (Low Speed)

Gradient

30°

Track Frame Oscilation

±10°

Total Weight

15,000 kg

Transportation Dimensions

9,000X2,300X3,000 mm
