Stainless Steel Tank Water Softener
Shaoxing Pengfeng Packaging Products Co., Ltd.- Condition：New
- Customized：Customized
- Voltage：220V
- Composition：Water Treatment Equipment
- Processing Material：Resin
- Process：Thermal Processing
Base Info
- Model NO.：YL-II-70
- Control Mode：Flow Rate Type, Time Type
- Resin：001×7 Strong Acidic Cation-Exchange
- Working Ambient Temperature：5-50centigrade
- Relative Humidity：Less Than 95%(25centigrade)
- Hardness of Raw Water：Less Than 8mmol,L
- Hardness of Effluent：Less Than 0.03mmol,L
- Inlet Water Pressure：0.2 to 0.4MPa
- Free Chlorine：Less Than 0.3mg,L
- Suspended Solid：Less Than 0.5mg,L
- Iron Content：Less Than 0.3mg,L
- Transport Package：Plywood Case Into Container
- Specification：CE, ISO
- Trademark：YLD
- Origin：Jiangyin, Jiangsu, China
- HS Code：8421219990
- Production Capacity：5000 Set,Year
Description
Single tank fluid ,model water output
(M 3 /Hour) dimension of can
diameter*height
(mm) salt box
(L) consumption on resin
(KG) Connecting pipe(inch) YL-I-0.5 0.5 200×1200 60 25 3/4 YL-I-1 1 250×1400 60 25 1 YL-I-2 2 300×1400 100 50 1 YL-I-3 3 350×1650 200 75 1 YL-I-4 4 400×1800 200 100 1.5 YL-I-5 5 500×1850 200 150 1.5 YL-I-6 6 600×1850 200 200 1.5 YL-I-10 10 750×2400 350 350 2 YL-I-16 16 900×2400 1000 600 2 YL-I-20 20 1000×2400 1500 700 3 YL-I-28 28 1200×2400 2000 1000 3 YL-I-50 50 1500×2400 2000 1500 3
(M 3 /Hour)
diameter*height
(mm)
(L)
(KG)
