• Model NO.：ACM600
• Power：16kw
• Material：Stainless Steel 304#
• Weight：500kg
• Electricity Requirement：380V,220V 50Hz,60Hz 3phase
• Production Load：600kg,H
• Suitable for：Green Peas, Broad Beans, Peanuts, Sunflower Seeds
• Compressed Air Supply：0.6-0.8MPa
• Port：Guangzhou
• Operating Mode：Automatic
• Name：Advance Technology Auto Nuts Coating Frying Line
• Transport Package：Wooden Box
• Specification：2.4m * 2m * 3.5m
• Trademark：Handyware
• Origin：Foshan
• HS Code：8438800000
• Production Capacity：500~600kg,H

NoModeDescription1WeigherThis is the default mode. Under this mode, the upper tank stops dispensing after the weight of the lower tank reaches a defined setting (this is defined under Appendix I: Parameter Page).2TimerThis mode is selected if the physical weigher is faulty. In this mode, upper tank will stop dispensing after a defined timing (this is defined under Appendix I: Parameter Page). Note the modes will need to be manually selected at the Parameter Page.
            b) Flour Input Subsystem
            The flour input subsystem consists of a flour tank, flour press and flour applicator. The flour tank may store up to 60KG of flour. The flour press consists of a motor and screw blades to push the flour into the flour applicator. Flour is fed to the coating pan via the flour applicator. The flour applicator consists of a conveying screw, motor and servo. The speed of the screw is controlled by the motor and servo. The servo is controlled by the PLC. The frequency of flour feeding to flour applicator and the speed of the screw in flour applicator can all be defined at the Parameter Page (See Appendix I).NoModeDescription1AutomaticThis is a recommended mode of operation. Parameters need to be pre-set in Parameter Page. Operator may then run the machine by activating "Run"/"Stop" buttons at Automatic Operation Page (See Appendix I). 2.ManualThis mode is typically used during testing and calibration (See Appendix I: Manual Operation Page)

Technical information

Automatic coating machineDimensions(L*W*H)2.4m X 2m X 3.5mTotal power16KWWeight500kgElectricity requirement380V/220V 50Hz/60Hz 3phaseProduction load600kg/hSuitable forGreen peas, broad beans, peanuts, sunflower seeds, small fishesMaterialSS304Compressed air supply0.6-0.8MpaPlace of originFoshanPort GuangzhouOperating modeAutomatic
Our strength
   a) Labour cost saving
      1) Automatic, require initial setup only
      2) Save 1-2 person effort(typical effort to achieve equivalent load using conventional batch coating process)
   b) Top quality
      Manufactured using high quality stainless steel(304)
   c) Excellent end product
      Consistent end product shape, size and quality, as process is automated
   d) Ease to use
      1) Centralized touch screen control to manage end product formulation
      2) Saved formulation easily reusable
   e) Flexible end product
      1) Suitable for coating on all kinds of peas and seeds(eg peanuts, green peas, sunflower seed and broad beans)
      2) May to add flavouring during coating, or apply seasoning after coating

Unique characteristics
  1) Similar machine in US are sold 2 times or more
  2) Production load can reach 600kg/h or more
  3) This machine can be easily operated
  4) This machine can handle multiple different products, including fish, broad bean, green pea, sunflower seed and peanut

End product
a) Coated peanuts
b) Coated green peas
c) Coated broad beans
d) Coated sunflower seeds



If have any inquiries or comments, please feel free to ask me.
