Denim Jeans Laser Printing Engraving Machine
Xiamen Teyate Aluminum Co., Ltd.- Laser Visibility:Invisible
- Applicable Material:Nonmetal
- Cooling System:Air Cooling
- Technical Class:Pulse Laser
- Laser Wavelength:CO2 Laser
- Laser Classification:Gaseous Laser
Base Info
- Model NO.:CKD-CMLA-30,50,100
- Type:CO2 Laser Marking Machine
- Marking Method:Scanning Marking
- Laser Source:30,50,60W
- Warranty:12 Months From Shipping Date
- Marking Scope:100*100mm,200*200mm
- Shipping Time:3-5 Work Days After Payment
- Transport Package:Wooden Box
- Specification:CE: EMC, LVD, MD
- Trademark:CKD LASER
- Origin:Shenzhen, China
- HS Code:8486204900
- Production Capacity:200 Sets,Month
Description
laser source30W/40/70Optional marking scope recommendCKD-CMLA-30/40100*100mmbig marking scope weaken laser power, there are suitable recommend for you.CKD-CMLA-70Optional: 100*100/150*150/200*200mmComputerWindow 7/10Computer language: English as basic, you can choose your language after receiving. Marking SoftwareEzCad2Language: English, Chinese, Korean, Japanese Control BoardBJJCZOriginal newest version Rotarychuck diameter: 50mmOptional part, for jewelry markingOptionalchuck diameter: 80mmOptional part, for tuber or column markingchuck diameter: 100mmOptional part, for bigger column, cup, bottle, etc.Foot switchwithstandard attchment, every type with Focusing toolwith help you find right focus easily, standard attchment, every type with
PARAMETER
ADVANTAGE
* Multi-functions: carving/engraving/marking/cutting.
* Series number jumping mark, photo amrk, vector logo mark, etc.
* Anti-interference, stability.
* High accuracy, long time use without correction.
* Compact structure, all-in-one machine, easy lean and operation.

CONTACT US / ONLINE SERVICE
Please send your inquiry or place order with certain configuration directly by following dialog box, we will reply you immediately.
Please tell us your application if you need configuration suggestion.
PARAMETER
Parameters | Unit | Data | Data |
Type | CKD-CMLA-30/40 | CKD-CMLA-70 | |
Power | W | 30/40 | 70 |
Laser Type | CO2 laser | CO2 Laser | |
Central Wavelength | um | 10.6 | 10.6 |
Optional Marking Area | mm | 75*75/140*140 | 75*75/140*140/175*175/210*210 |
Marking Speed | mm/s | ≤7000 | ≤7000 |
Software | EzCad | EzCad | |
Life-span of Fiber Laser Module | hrs | 45000 | 45000 |
System Operation Environment | Windows 7/8/10 | Windows 7/8/10 | |
Cooling Mode | Air cooling | Air cooling | |
Temperature of Operation Environment | ºC | 15~35 | 15~35 |
Power Source Requirement | 90-240V/50-60Hz/2KVA | 90-240V/50-60Hz/2KVA | |
Computer | With | With | |
Dimension (L*W*H) | mm | 980*615*1480 | 980*615*1480 |
ADVANTAGE
* Multi-functions: carving/engraving/marking/cutting.
* Series number jumping mark, photo amrk, vector logo mark, etc.
* Anti-interference, stability.
* High accuracy, long time use without correction.
* Compact structure, all-in-one machine, easy lean and operation.
