Low Cost China High Quailty Mushroom Dryer Machine (DW1.2X10)
WUXI HENGTONG COLOR PRINTING & PACKAGING FACTORY- OEM：Provide
- Material Equipment：Stainless Steel
- Technical Service：Provide
- Environmental Protection：ISO14001
- Structure：Transport Drier
- Operational Method：Continuous
Base Info
- Model NO.：DW1.2x10
- Operation Pressure：Atmospheric Dryer
- Heating Mode：Transmission
- Movement Way：Combined
- Transport Package：It Need Ship by Standar Container
- Specification：ISO9001-2008, ISO14001
- Trademark：HC
- Origin：China
- HS Code：8419399090
- Production Capacity：3sets,Month
Description
ModelDW-1.2-8 DW-1.2-10 DW-1.6-8 DW-1.6-10 DW-2-8 DW-2-10 DW-2-20 Quantity of unit 4 5 4 5 4 5 10 Width of belt(m) 1.2 1.6 2 Length of dry section(m) 8 10 8 10 8 10 20 Thickness of raw material spreading(mm) 10-80 Operation temperature(oC) 50-140 Steam pressure(MPa) 0.2-0.8 Steam consumption (kg/h) 120-300 150-375 150-400 180-500 180-500 225-600 450-1200 Drying time (h) 0.2-1.2 1.25-1.5 0.2-1.2 0.25-1.5 0.2-1.2 0.25-1.5 0.5-3 Drying capacity
(kg water/h) 60-160 80-200 85-220 100-260 100-260 120-300 240-600 Total power (kw) 11.4 13.6 14.6 18.7 19.7 24.5 51
Overall dimensions
L(m) 9.56 11.56 9.56 11.56 9.56 11.56 21.56 W(m) 1.49 1.49 1.9 1.9 2.32 2.32 2.32 H(m) 2.3 2.3 2.4 2.4 2.5 2.5 2.5 Weight (kg) 4500 5600 5300 6400 6200 7500 14000
