Bmph 160cc 101-1036 Char Lynn Eaton Hydraulic Motor for Drilling Rig
Guangzhou Cospack Packaging Technology Co., Ltd.- Certification：CE
- Power Rating：12kw
- Number of Poles：10
- Speed：High Speed
- Type：Hydraulic Power Units
- Displacement(Cc/Rev)：160cc
Base Info
- Model NO.：OMPH 36,50,80,100,125,160,200,250,315,400,500
- Hole Middle Distance：106.4mm
- Cylinde Parallel Shaft Size：25mm
- Flange：Standard 2 Hole Diamond Flange
- Max Pressure(MPa)：17.5
- Ports and Drain Port：G1,2, G1,4
- Continuous Max Speed(Rpm)：302
- Continuous Max Torque(N.M)：360
- Material：Rust-Proof Cast Iron
- Warranty：One Year
- Hydraulic Power Units：Gear Pump
- Auxiliary Components：Hydraulic Motor
- Pressure Control Valve：Orbital Motor
- Hydraulic Control Unit：Hydraulic Motor
- Hydraulic Motor：Omp Hydraulic Motor
- Transport Package：Sale Packing Contians Carton or Wood Case
- Specification：CE
- Trademark：Blince
- Origin：Guangdong Province, China (Mainland)
- HS Code：8412291000
- Production Capacity：1000 Units Per,Month
Description
typeOMP
OMPH
36 OMP
OMPH
50 OMP
OMPH
80 OMP
OMPH
100 OMP
OMPH
125 OMP
OMPH
160 OMP
OMPH
200 OMP
OMPH
250 OMP
OMPH
315 OMP
OMPH
400 OMP
OMPH
500 Geometric displacement 36 51.7 77.7 96.2 120.2 157.2 194.5 240.3 314.5 389.5 486.5 Max.speed.(rpm) con. 1500 1150 770 615 490 383 310 250 192 155 120 int. 1650 1450 960 770 615 475 385 310 240 190 150 Max.torque(N.m cont. 55 100 146 182 236 302 360 383 375 360 385 int. 76 128 186 227 290 370 440 460 555 525 560 Max.output(KW) cont. 8.0 10.0 10.0 11.0 10.0 10.0 10.0 8.5 7.0 6.0 5.0 int 11.5 12.0 12.0 13.0 12.0 12.0 12.0 10.5 8.5 7.0 6.0 Max.pressure
Drop(Mpa) cont. 12.5 14 14 14 14 14 14 11 9 7 6 int 16.5 17.5 17.5 17.5 17.5 17.5 17.5 14 14 10.5 9 Max.flow(L/min) cont. 55 60 60 60 60 60 60 60 60 60 60 int. 60 75 75 75 75 75 75 75 75 75 75 OMP50-2AD (OMP-1510310) OMP50-2AD (OMP-1510610) OMP50-2CD (OMP-1510300) OMP50-2CD (OMP-1510600) OMPH50-H2RS (OMP-1517041) OMP50-2ED (OMP-1510330) OMP50-2ED (OMP-1510630) OMP50-4BD (OMP-1515001)
Blince manufactured factory estblish in 2004s , we are full experience to technical adis for hydraulic motor omr /omrs/omm /omp/omph/omt/omv/oms/omsy/ok/oz/ 6kseries & vane pump( PV2R, VQ ,V ,SQP Series.pump cartridge)
We own ourself brand in 2010 years "blince" ,to enlarge name plate efforts ,also support customization
Our order track information " & perfomance certificate . please entre in the "company profile part " to seek
If you have any requests, to get from us! ! I am so glad to provide our best services
