Basic Info.

Model NO. XRYS1000 Certification ISO9001:2008, CE Model No. Xrys 1000 Shredding Room 1000*1800mm Blades Materials Skdii D2 DC53 Voltage According to Customer Main Electrical Equipments Schneiders Reducer Guomao or Boneng Weight 4800kg Delivery 45-50 Working Days Rotor Diameter 500mm Hydraulic Power 2.2kw Output 800-1200kg/H PLC Control Siemens Rotary 25 Rpm Package Wooden Pallet or Film Packed Transport Package Film or Wooden Case Specification 5000x4500x3000mm Trademark S&K Origin China HS Code 84778000 Production Capacity 80sets/Year

Product Description

                                              XRYS Series Pre-shredder machine

Operating principles:

• The material loaded in bales or by means of spider is progressively chopped by the rotor.
• During the rotation the rotor cuts a quantity of material proportional to the section of the rotating blade.
• The shape and the number of blades are chosen according to the applications to optimize the cutting efficiency.
• This peculiar operation of the single-rotor shredder enables the machine to self adjust the feeding avoiding any risk of obstruction.

Feature & Function:The single-rotor shredders are particulary suitable for the pre-grinding of a wide range of materials.
The installation of the shredder XRYS serie  allows to automatize the grinding lines or the pre-treat-ment of the recycling plants.
By feeding the grinder with pre-cut material the production is increased and the energetic consumptions are reduced.

Technical parameters:

Model	Fixed blades	Rotary blades	Rotor diameters	Chamber size	Power	Output	Weight
XRYS1000	12 pcs	20 pcs	500 mm	1000*500 mm	55kw	1000-1500 kg/h	6000 kg
XRYS1200	14 pcs	24 pcs	650 mm	1200*650 mm	75kw or 90kw	1500-2500 kg/h	10000 kg
XRYS1600	20 pcs	32 pcs	650 mm	1600*650 mm	90kw or 110kw	2500-4000 kg/h	13000 kg

Application Area:
Molded Articles
Bottles
Copper & aluminium electric cables
Bituminos sheats
Bales of plastic film
Wood & papers
PP bags & Jumbo bags


Our Certification:
