500L Insulated Heating Tank

Dongguan DianYa Packaging MFG. Co., Ltd.
  • Process：Thermal Processing
  • Power Source：Electric
  • Certification：CE, ISO9001
  • Automatic Grade：Manual
  • Application：Milk, Yogurt, Cheese
  • Customized：Customized

Base Info

  • Model NO.：insulated heating tank
  • Heating Type：Steam Heating
  • Jacket Type：Dimple Jacket , Spiral Coil
  • Mixing Speed：20~3600rpm Optional
  • Contact Part：Ss316L , Ss304 Optional
  • Insulation：PU , Rock Wool
  • Polish：Food Grade
  • Transport Package：Suitable for Sea Transportation
  • Specification：500-3000Liter
  • Trademark：Ranking
  • Origin：China
  • HS Code：847892
  • Production Capacity：5000PCS Per Month

Description

Stainless steel heating tanksJacketed Cooking KettlesStainless Steel 316 TanksStainless Steel Agitated Mixing TanksStainless Steel Insulated TanksStainless Steel Jacketed Mixing TanksStainless Steel Jacketed Process TanksStainless Steel Pressure TanksStainless Steel Product Storage TanksConical mixing tanksStainless steel hydrogenation reactorGlycol cooling tank The above listed items are what we can offer but not all that we can offer
500L insulated heating tank
 500L Insulated Heating Tank1000L insulated mixing tank, double-wall mixing tank, 304 or 316L stainless steel dimple jacketed and insulated tank.
Vessel dimensions:
  • 43" diameter x 45" deep
  • with slant style bottom
  • Equipped with 14" diameter man way
  • with bolt down cover
  • CIP spray balls with 1"OD / 1½"ID Tri-clamp style connections
  • thermowell
  • 2" wide baffles
  • top mounted 3 hp bottom sweep agitation
  • Unit mounted on (3) legs
  • with a 2½" OD / 2" ID Tri-clamp style side bottom discharge
  • with 15" ground clearance.
500L Insulated Heating TankInsulated mixing tank main specificationTop Ports:(2) 1½"OD / 1"ID Tri-clampJacket Ports:(2) 1" NPTOAD50"L x 47"W x 68"HThe Ranking Machinery Team Advantages
  • Complete Line Integration
  • Machinery Retrofit and Recondition
  • In-House Testing, Proof of Concept, Trial Runs
  • On-Site Installation and Training
  • Factory Acceptance Testing
  • 25 Years in Business
200L insulated heating tank picture500L Insulated Heating Tank
1000Liter 1T Insulated mixing tank Non-insulated mixing tank price
 (Stainless Steel 304 / 316L Mixing Tank)
Due to stainless steel raw material market keep changing, the stainless steel mixing tank prices will change accordingly. we are unable to make a price list for our stainless steel mixing tanks but we are ready to offer you the prices for any stainless steel mixing tanks and other 316L / 304 mixing equipments that you are looking for. So, please do not hesitate, sending your inquiry to our on line service team and get the latest price now.
