Zgyx 415 DTH Hammer Surface Drill Rigs
Ruian Shengxiang Packaging Machinery Co., Ltd.Base Info
Description
ZGYX-415 crawler mounted DTH drilling rig technical figuresRig model ZGYX-415 Diesel engine model Yuchai YCD4R12T-70 Engine power 50 KW Drilling depth 15-20m Drilling diameter Φ90-Φ127mm Working air pressure 0.8-1.45 MPa Air consumption 7-13 m3/min Drilling pipe diameter Φ60,Φ76 Length of drill pipe 3.0m One push length 3.0m Tramming speed 2.5km/h Climbing ability (Max.) 25° Ground clearance (Min.) 250mm Rotation speed 0-110 rpm Rotation torque 1850 N.m Propulsion 15KN Lifting capacity 250KN Propulsion mode Cylinder chain Weight 4500kg Transportation dimension 5500x2000x2100mm
