300m Mining Exploration Hydraulic Core Drill Rig (HGY-300)
Ruian Shengxiang Packaging Machinery Co., Ltd.Base Info
Description
Related Photos We supply the plenty of drilling rig spare parts for all customers, no worries for after -sale services!Type HGY-300 Drilling Rig Drilling depth(m) 300 Drilling rod diameter(mm) Φ50 Head angle range 0~360° Cylinder stroke(mm) 400 Spindle speed(r/min) Positive rotation rate: 34671151892381563075318681094
Reverse rotation rate: 38173Spindle hole diameter(mm) Φ65/Φ96 Spindle output torque(N.M) 3100 Spindle stroke(mm) 530 Spindle driving force max.(KN) 40 Spindle lifting power max.(KN) 60 Lifting speed (m/s) 0.300.591.011.662.09 Single rope lifting power(KN) 30 Steel wire rope diameter(mm) Φ13 Mode of chuck Full hydraulic chuck or ball-type chuck Weight(power unit excepted)(kg) 1200 Dimensions(LxWxH)(mm) 2000x900x1600 Diesel engine 495D(26.5KW) Electrometer Y180L-4(22KW)
