PE,PP,ABS... Max container capacityL1000 Output(dry cycle)pc/hr150 Machine dimension(L×W×H)M9.5×5.1×6.5 Machine weightT55 Clamping Unit   Clamping forcekn1000Mold platen size(W×H)mm1400×1600 Platen moving strokemm800-2400 Platen moving strokemm1600 Max Mold Size (WxH)mm1200×1500 Mold thicknessmm810-950 Power   Servo oil pump motor powerKW37 Servo pump displacementL/MIN200 Blow pressureMPA1 Air consumptionM3/MIN1.8 Cooling water pressurempa0.5 Water consumptionL/min60 Average energy consumptionKW80-100 Extruder unit   Screw diametermm120 Screw L/D ratioL/D25HDPE Melting capacit for HDPEkg/hr180-250 Number of heating zonezone6 Screw heating powerkw30.2 Screw fan powerKW0.6 Extruder motor powerkw90 Die head   Number of heating zone for single die headzone6 Heating power for single die headkw31.2 Max die-pin diametermm550 Accumulator capacityL45(HDPE) Accumulator weight(HDPE)KG33

Delivery Time:
- No later than 90 days after receipt of the deposit

Training:
- We provide training service for two or three operating men for free (but the cost for trainer's board and lodging is not included).

Installation:
- The supplier will send one specialist to test run the machine until it is running in normal state.

Guarantee:
- Our guarantee is valid for a period of 12 months. If the malfunction caused of the machine's self quality, we will troubleshoot it for free.

Auxiliary Equipments:
- Auxiliary equipments for production line are available and optional, please kindly ask for quotation.
