ZQ88-M6ZQ128-M6ZQ168-M6
 275/88416/128619/168International size ratingINJECTION SYSTEMABCABCABCShot volume           cm 3129163201215263316291349463Shot weight     g121153189196239287273328435(PS)         oz4.25.46.66.98.410.19.611.515.2Screw diameter       mm323640384246424653Injection pressure    Mpa214169137193158132190169120Screw L: Dratio       -----23:120:118:122:120:118:123:120:118:1Screw stroke             mm160190200Screw speed (stepless)   r/min0-2150-2200-234CLAMPING SYSTEMZQ88-M6ZQ128-M6ZQ168-M6Clamping force           KN88012801680Opening stroke           mm320380430Platen size         mm×mm550×550620×620700×700Space between tie bars mm×mm360×360410×410460×460Max.daylight                mm680810930Mold thickness (Min-Max)   mm150-360150-430180-500Hydraulic ejection stroke      mm100125140Hydraulic ejection force        KN314250POWER UNITZQ88-M6ZQ128-M6ZQ168-M6Hydraulic system pressure    Mpa1617.517.5Pump motor                 KW9.51115Heating capticy           KW6.58.99.8Number of temp control zones-----3+nozzle3+nozzle3+nozzleNote: The specifications are subject to change without notice for the further improvement.
