Basic Info.

Model NO. FC-45 Sylinder Dia 45mm Revoling Speed of Screw 60rpm Extrusion Output 20kg/H Power for Main Machine 11kw Conductor Diameter 0.6-2.0mm Finished Wire Diameter 1.0-2.8 Temperature Control 7phase Pay off Type Dynamic or Tension Wire Feeding Evacuating Device Vacuum Generator High Output 20kg/H Transport Package Common Specification ISO9001 Trademark FC Origin China HS Code 8477209000 Production Capacity 30set/One Month

Product Description

Product Parameter:
1)Power:11kw AC motor
2)Reducer gear box:milling gear imported from Italy ZLYJ133-II,the specialized reducer gear box for extrusion
3)Screw:GH113,45MM,ratio:25:1
4)Screw drum:GH113
5)Screw speed:10-80r/min
6)Hot dip:220V voltage,3 phase screw drum,cast copper heater,each phase 2.5KW;1 phase clamp,cast copper heater,1000W.
7)Clamp type:flange bolt fix way
8)Cooling way:3 sets screw cooling high voltage centrifugal fan,60W power,the clamp cooling itself .
9)Total power:11+3*2.5+1+3*0.06=19.68KW
10)Dimension:L2000*W1300*H1500mm
11)Vacuum installation
12)Weight:800KG
13)Spare parts:1set clamp cast copper heater,2 bar hot dip
Please feel free to contact me if you have any questions.
