• Model NO.：GDB
• Lollipop Weight：as Per The Lollipop Size
• Diameter：as Per The Lollipop Shape and Size
• Depositing Speed：25-30n,Min
• Steam Requirement：250kg,H,0.5-0.8MPa
• Compressed Air Requirement：0.2m3,Min,0.4-0.5MPa
• Electric Power Needed：18kw,380V
• Total Length：17m
• Gross Weight：4000kg
• Specification of The Stick：L60-100mm,Diamater3.2-4.2mm
• Transport Package：Wooden Case
• Specification：CE, ISO9001
• Trademark：SHINWEI
• Origin：China
• HS Code：84382000
• Production Capacity：150kg,H

As per candy size
speed
25~30 n/min
Steam consumption
Steam pressure
250kg/h, 0.5~0.8MPa
300kg/h, 0.5~0.8MPa
400kg/h, 0.5~0.8MPa
500kg/h, 0.5~0.8MPa
Compressed air consumption
Compressed air pressure
0.2m3/min,
0.4~0.6MPa
0.2m3/min,
0.4~0.6MPa
0.25m3/min,
0.4~0.6MPa
0.25m3/min,
0.4~0.6MPa
Electric power needed
18kW/380V
27kW/380V
34kW/380V
42kW/380V
Total length(m)
17
19
19
22
Gross weight
3500 kg
4000 kg
4500 kg
5000 kg




PROCESSING CHART:

Raw material melting → Conveying → Filter → Storage → Constant syrup conveying →

Pre-heating → Micro-film vacuum cooking → Discharging → Mixing with flavor and Color

→ Depositing → Cooling → De-moulding → Conveying → Packing
