Bottle type specification
 cavity4output(PCS/HR)3200-3500Max. volume (L)2LBottle mouth maximum overall diameter (mm)28-38mmBottle biggest diameter100mmBottle maximum height330mm
Power specifications
 Light tube quantity32pcsLight tube power1.25kwMaximum heating power40kwAll electric machine installation43kwActual consumption21.5kw
Air pressure specification
 Work pressure7-9kg/cm2Low-pressure gas consumption1600Ltr/minBlow bottle pressure25-35kg/cm2Higher -pressure gas consumption3000 Ltr/min
Frozen water specification
 Work pressure5-6 kg/cm2Temperature range10Consumption8000kcal/hrFrozen water flow88Ltr/minMachine specificationSize of the machine4.5x1.6x1.9 (m)Weight of the machine3.5ton



1.Q:Are you a factory or trading company?
A:We are a factory

2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Taizhou City, Zhejiang Province, China, about 3 hours train from Shanghai by fast train. All our clients, from home or abroad, are warmly welcome to visit us!

3.Q:What is the payment of your machines ?
A:30% by T/T as down payment, 70% by T/T or L/C before shipment

4.Q:What is the delivery of your machines ?
A:30 days after down payment and drawing comfirmed

5.Q:How does your factory do regarding quality control?
A:Quality is priority. ZS People always attach great importance to quality controlling from the beginning to the end.

6.Q:How about after sales service?
A:One year spare parts for easy broken parts, long term technical support,  as customer demand, sending technicians to custoemr site for instatllion or trainning. at importance to quality controlling from the beginning to the end.


l.   Special design,high rigid compound die structure
2.  Wide adaptability, suitable for every type mould thickness
3.  Adjust convenience
4.  No mould rolling out
5.  More energy conservation,no need much air supply
6.  High burnish principal axis, with very precise polishing, light action and low noise.
7. Short mould stroke,quick action
8.  All ZG45 casting, with long timing process,very small transformation,can meet your precise request 100%
9.  Hig dead-weigh, ensure the steady during the opeartion
