Basic Info.

Model NO. md-h2 Film Thickness 0.008-0.08mm Max Extrusion Output 50kg/H Screw L/D Ratio 28:1 Cover Dimensions (M) 5*3.2*4.3 Transport Package Export Standard Packing Type Specification CE, ISO9001, SGS Trademark Mingde Origin China Production Capacity 100 Per Year

Product Description

Product Description
It is suitable for (HDPE), (LDPE) (LLDPE), which is widely used for packing foodstuff, garment, textile, daily-use articles and industrial products, etc.

1, The machine adopts single screw to extrude the material, two die heads to blow the film.
2, The screw stem and cylinder are made of 38CRMOALA high quality alloy steel after fine finishing and nitride treatment, which has high hardness, strong resistance to corrosion, durable service.
3, The die head is plated with hard chrome, of screw mandrel type structure with even and smooth discharging, the blown plastic film has fine finishing; The blower is of labyrinth structure with even air output.
The coiling unit adopts pressure friction rewinding or center rewinding, which is driven by torque motor, with even and smooth rewinding and easy roll changing.
4. Optional equipment


Double winder Rotary die head Auto loader Double lip air ring Air shaft Corona treatment Fast screen changer Air compressor All roller pneumatic type
