The whole machine parameters

Model

FD600

FD400

FD300

FD200

Drill hole depth

600m

400m

300

200

Maximum opening diameter

350mm

350mm

325mm

305mm

Final hole diameter

140mm

140mm

140mm

140mm

Drill pipe diameter

76/89/102mm

76/89/102mm

89/102mm

76/89/102mm

Walking speed

2.5km/h

2.5km/h

2.5km/h

2.5km/h

Power

115KW

95KW

84KW

65KW

Air pressure

1.7-3.5MPa

1.7-3.5MPa

1.7-3.3MPa

1.7-3.0MPa

Air consumption

17-35m3/min

17-35m3/min

17-35m3/min

17-30m3/min

Drill pipe length

1.5m/2m/3m

1.5m/2m/3m

1.5m/2m/3m

1.5m/2m/3m

Rig lifting force

30T

24T

28T

18T

Swing speed

45-115rpm

45-115rpm

55-115rpm

50-70rpm

Size(mm)

5400*2100*2850

5200*2000*2780

5500*1950*2780

3800*1700*2350

Weight

12Ton

10Ton

9Ton

5.5Ton

1. Packaging:  1)Wrapped by proctective film;

                        2)Packed by standard import & export wooden cases or carton boxes.

2. Shipping: By logistics; by automobile; by train; by shipping; by air etc.

Company Information:

Henan Yugong Machinery Co.,Ltd. has more than 500 employees,including more than 30 senior technical staff and 30 international sales persons.We can supply high quality and professional services.We warmly welcome your corporation from all fields and build great future for us all.

FAQ:

1. Q: Are you trading company or manufacturer?

    A: We are original equipment manufacturer.

2. Q: How long is your delivery time?

    A: It is according to the model and quantity.

        Generally it is 3-5 days if the machines are in stock.

        It will be 15-30 days if you want to customize the machines.

3. Q: Do you provide samples? Is it free or extra?

    A: Yes, we could offer you the sample machine.

        But it's not free. You need to pay for the sample and the cost of freight.

4. Q: What is your terms of payment?

    A: We accept T/T, Western Union, Money Gram, Paypal, Alibaba Escrow etc.

        Payment<=USD 5000, 100% in advance.

        Payment>=USD 5000, 30% T/T in advance, balance before shipment.
