Model NoRHD160RHD250RHD315RHD450RHD500Working range(mm)40,50,63,
75,90,110,
125,140,16075,90,110,
125,140,160,
180,200,225,25090,110,125,140,
160,180,200,
225,250,280,315200,225,250
280,315,355,
400,450200,225,250,
280,315,355,
400,450,500Max temperature in
heating mirror270°C270°C270°C270°C270°CTemperature difference in heating mirror±5°C±5°C±5°C±5°C±5°CPressure working range0-8MPa0-8MPa0-8MPa0-8MPa0-8MPaHeating power1kW2kW3kW5.4kW6.6kWMilling power0.7kW1.1kW1.1kW1.5kW1.5kWHydraulic station power0.75kW0.75kW0.75kW1.5kW1.5kWTotal power2.45kW3.85kW4.85kW8.4kW9.6kWPower supply220V/50HZ220V/50HZ220V/50HZ380V/50HZ380V/50HZTotal weight90kg115kg210kg400kg500kgDimension
(mm)Machine body838x377x386886x475x4481016x570x5751240x718x7061280x765x760Tool stand580x344x465670x670x690750x635x672640x780x912640x796x1035Hydraulic station557x318x450557x318x450557x318x450640x318x45864440x318x458





Model NoRHD630RHD800RHD1000RHD1200RHD1600Working range(mm)355,400,450,
500,560,630500,560,
630,710,800560,630,710,
800,900,1000630,710,800,
900,1000,1200900,1000,
1200,1400,1600Max temperature in
heating mirror270°C270°C270°C270°C270°CTemperature difference in heating mirror±7°C±7°C±7°C±7°C±10°CPressure working range0-14MPa0-14MPa0-14MPa0-14MPa0-20MPaHeating power9.3kW12kW15kW19.8kW48kWMilling power1.5kW2.2kW3kW4kW5.5kWHydraulic station power1.5kW2.2kW2.2kW4kW5.5kWTotal power12.3kW16.4kW20.2kW26kW959kWPower supply380V/50HZ380V/50HZ380V/50HZ380V/50HZ380V/50HZTotal weight700kg1120kg2200kg2875kg5120kgDimension
(mm)Machine body1575x1130x25402020x1490x13502450x1880x16402780x2140x18753805x2175x2170Tool stand735x982x12201310x820x15151310x850x18151520x1035x21501065x1885x2440Hydraulic station640x318x458690x318x466690x318x466690x318x466905x375x578
