Basic Info.

Model NO. SJ-45-50 Machine Weight 2-3.5t Certification CE, ISO9001:2008 Main Motor Power 5.5-24kw Assistance Machine Power 0.75kw Die Head Diameter 50-300mm (Choose Freely) Material LDPE Lope LLDPE Transport Package Film Wrap Specification CQC, ISO9001, CE, SGS Trademark YUNBANG Origin china HS Code 84773010 Production Capacity 30-50 Kgs/G

Product Description

It applies to blow various LDPE, HDPE and LLDPE plasticfilms, widely applying to food, fruit, clothing, textile, vesttype bag and etc. Packingof civil industrial products.

Feature:
Mode SJ-50-85 squeezing machine is adopted rotatory die head, machine tube is adopted 38CrMoAl, having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.

FM-600 auxiliary machine can adjust and operate freely within the range of 700mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.
Rolling up device with double-drawing in and do-uble cutting ope, its power is adopted moment motor, with friction plate, it can keepsuitable tension, drawing in and rolling up in good order, easy to change roll.

Technical Parameters:
Power of Main Motor: 5.5-24KW
Assistance Machine: 0.75KW
Heating: 12KW
Die-Head: Φ 50-300mm Choose freely
Screw Diameter: Φ 45/50/55/65mm Choose freely
Screw L/D Ratio: L/D 28: 1
Screw Speed: 10-100r/min
Max Ouput: 30-70kg/h
Film Thickness: 0.08-0.10 mm
Film Width: 50-1200 mm
Weight: 2-4.5T

Power	5.5-24KW
Assistance Machine	0.75KW
Heating	12KW
Die-Head	Φ50-200mm Choose freely
Screw Diameter	Φ45/50mm Choose freely
Screw L/D Ratio	L/D 28:1
Screw Speed	10-100r/min
Max Ouput	30-50kg/h
Film Thickness	0.008-0.10 mm
Film Width	50-600 mm
Weight	2-4.5T
