Basic Info.

Model NO. ABLB90II Certification CE Product 10L Oil Drum Extrusion Blow Molding Machine Screw Diameter 90mm Station Double Station Parison Controller Available Auto-Deflashing Unit Available Transport Package Film Packaging Specification CE/SGS Trademark Apollo Origin Jiangsu, Zhangjiagang HS Code 8477301000 Production Capacity 180-200PCS/H

Product Description

Basic installation including

   Die head: Center-feed die head
   Extrusion system: Adopt world-famous brand automatic temperature controlling device. Drive the screw with electromagnetism motor reducer to realize stepless regulating.
   Clamping device: Adopt bi-directional synchronous clamping device with double axis single cylinder to stabilize equipment well
   Blowing device: with upper blowing type
   Hydraulic system: The whole hydraulic system adopts world-famous brand controlling components and proportional controlling circle.
   Electric controlling system: Adopt programmable controller made in Mitisubishi , Japan. Every electric component is of world-famous brand.
Unit price (including one series of spare parts)
   Unite price (including one series of spare parts for wearing parts)

Max. Product volume	15 liters
Out put capacity	160pc/h
Screw diameter	90mm
Screw L/D ratio	24L/D
Screw drive power	45KW
Screw heating capacity	8KW
No.of heating zone	4 zones
Output of HDPE	128KG/H
Oil pump drive power	11KW
Clamping force	108KN
Max.size of mold	240-660mm
Mold stroke	530X 550mm
Max.die diameter	180mm
Blowing pressure	0.6mpa
Air Volume	0.9M³/MIN
Cooling water pressure	0.3mpa
Water consumption	90L/MIN
Size of Machine	4.2x3x3.2m
Weight of machine	11ton
