• Model NO.：HZ342
• Certification：Is09001:2000, SGS
• Export：Global
• Kind：Diamond Saw Blade
• Transport Package：PVC Bag, Box, Cartons or as Request
• Specification：900mm
• Trademark：Huazuan
• Origin：Quanzhou, Fujian, China
• HS Code：82023910
• Production Capacity：10000 Set,Month

Basic Info.

Model NO. HZ342 Certification Is09001:2000, SGS Export Global Kind Diamond Saw Blade Transport Package PVC Bag, Box, Cartons or as Request Specification 900mm Trademark Huazuan Origin Quanzhou, Fujian, China HS Code 82023910 Production Capacity 10000 Set/Month

Product Description

Diamond segment blades for Sandstone (HZ342)

Advantage:
1. High quality
2. Competitive price
3. Easy and smooth cutting
4. Long lifespan and stable performance
Segment is the main part of diamond tools, we provide diamond segments for cutting granite, marble, sandstone, limestone, and other stone cutting applications, also ceramic, concrete, asphalt, etc. Our diamond segments are working very well specially on granite & Marble, the diamond saw segment dimension is available according to customer's requirements. We aim to improve the diamond segments cutting efficiency meanwhile reduce the cost

Diameter(mm)	Segment dimension L*W*H	Core thickness (mm)	Segment number (pcs)
250	40*3.0*10	1.8/2.0	18
300	40*3.0*12(15)	1.8/2.2/2.4	21
350	40*3.2*12(15)	1.8/2.2/2.4	24
400	40*3.4*12(15)	2.2/2.6/2.8	28
450	40*4.0*12(15)	2.5/2.8/3.3	32
500	40*4.2*12(15)	2.8/3.0/3.2	36
550	40*4.2*12(15)	3.0/3.5	40
600	40*4.6*12(15)	3.0/3.6	42
700	40*5.6*12(15)	3.6/4.0	46
800	40*5.6*12(15,20)	4.5/5.0	46
900	24*6.8/6.0*15(20)	5.0	64
1000	24*7.2/6.4*15	5.0	70
1100	24*7.4/6.8*15	5.5	74
1200	24*7.5/6.5*15(20)	5.5	80
1300	24*8.5/7.8*15(20)	6.0	88
1400	24*8.8/8.2*15(20)	6.5	96
1600	24*9.2/8.4*15(20)	6.5	108
1800	24*10/9.2*15(20)	7.0	120
2000	24*10.5/9.5*15(20)	8.0	128
2200/2300	24*11.5/10.5*15(20)	8.5	132/136
2500	24*11.5/10.5*15(20)	9.5	140
3000	24*13.0/12*15(20)	10	160
3500	24*13.5/12.5*20(30)	11	180

Used for granite, marble limestone, sandstone, basalt, concrete, bitumen, ceramic and so on. We can also make that according to your requirements.

About us:

Quanzhou Huazuan Diamond Tools Company was established in1994,

1. We are a professional diamond tools manufacturer coming scientific research, production and sales.

2. More than 20years research and development, quality of product and production technology are very mature.

3. We have export to Iran, America, Poland, Germany, Portugal, Spain, Italy, Turkey, Ukrain, Mexico, Brazil, India, Pakistan,
Thailand, Malaysia, Singaport, Australia, Saudi Arabia, Vietnam, Egypt, Russia...etc.
