30inch Laser Welded Saw Blade for Concrete Wall
Ningbo Passen Pack Co., Ltd.- Blade Type：Laser Welded
- Manufacturing Process：Brazing
- Application：Reinforced Concrete
- Outer Diameter (Inch)：30 Inches
- Outer Diameter：760mm
- Segment Size：40X5X10mm X42nos
Base Info
- Model NO.：1.2.2.3
- Thickness of Blank：3.5mm
- Slot Type：Straight U Slots
- Cutting Material：Concrete, Reinforced Concrete, etc.
- Horse Power of Machine：10-60 HP
- Technology：Laser Welding
- Package：Plywood Package
- Usage：Concrete Cutting
- Transport Package：Plywood Package
- Specification：GB
- Trademark：Johnson Tools
- Origin：China
- HS Code：8202391000
- Production Capacity：1000 PCS,Month
Description
Basic Info.
Model NO. 1.2.2.3 Thickness of Blank 3.5mm Slot Type Straight U Slots Cutting Material Concrete, Reinforced Concrete, etc. Horse Power of Machine 10-60 HP Technology Laser Welding Package Plywood Package Usage Concrete Cutting Transport Package Plywood Package Specification GB Trademark Johnson Tools Origin China HS Code 8202391000 Production Capacity 1000 PCS/MonthProduct Description
Cutting Saw Blade: 760mm Laser Welded Concrete Wall Saw Blade1. Description of Cutting Saw Blade: 760mm Laser Welded Concrete Wall Saw Blade
760mm Laser welded wall saw blade is one of our advantage products, mainly used for various types of reinforced concrete structure buildings' renovation and demolition, concrete cutting demolition, reinforced concrete cutting demolition, basic cutting removal, building cutting demolition, construction demolition cutting, wall cutting removal, floor cutting, ground cutting demolition, road cutting demolition, bridge demolition cutting, box girder cutting demolition, pillar cutting demolition.
2. Feature of Cutting Saw Blade: 760mm Laser Welded Concrete Wall Saw Blade
1) 100% laser welding technology.
2) Dry&Wet cutting.
3) High speed&fast cutting, smooth and long cutting life.
4) Fit to 3HP-85HP, or do as your request.
5) Installed for any brand wall saw machine.
3. Specification of Cutting Saw Blade: 760mm Laser Welded Concrete Wall Saw Blade
Diameter:760mm
Segment thickness:4.8/5mm
Segment height:10/12mm
Inner hole:25.4mm, 50mm, 60mm, 80mm or as your request
| Inch | Diameter (mm) | Teeth length (mm) | Teeth thickness (mm) | Teeth height (mm) | Teeth number (nos) |
| 30" | 760 | 40 | 4.8/5 | 10 | 46 |
| 30" | 760 | 40 | 4.8/5 | 12 | 46 |
Other size we could do
| Inch | Diameter (mm) | Teeth length (mm) | Teeth thickness (mm) | Teeth height (mm) | Teeth number (nos) |
| 24" | 600 | 40 | 4.8/5 | 10/12 | 36 |
| 28" | 700 | 40 | 4.8/5 | 10/12 | 40 |
| 32" | 800 | 40 | 4.8/5 | 10/12 | 46 |
| 36" | 900 | 40 | 4.8/5 | 10/12 | 52 |
| 40" | 1000 | 40 | 4.8/5 | 10/12 | 58 |
| 48" | 1200 | 40 | 4.8/5 | 10/12 | 62 |
| 56" | 1400 | 40 | 4.8/5 | 10/12 | 86 |
| 60" | 1500 | 40 | 4.8/5 | 10/12 | 90 |
| 64" | 1600 | 40 | 4.8/5 | 10/12 | 92 |
4. Packing and Shipping
Each laser welded saw blade is packed in white box, then 5pcs put in an export standard plywood, gross weight per plywood is limited within 75kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
