Mode



Pipe range

(mm)

extruders



Max. output

(kg/h)

Max. speed

(m/min)

Total power

(kw)

Line length

(m)

PVC-50x2

16-50

SJSZ51/105

150

6m

60kw

20m

PVC-40*416-40
SJMS65/1321608m70kw20m

PVC-63*2

16-63

SJSZ55/125

120

8m

45kw

20m

PVC-63*2
16-63SJSZ65/13214010m65KW22m

PVC-110

50-110

SJSZ65/132

150

6m

60kw

24m

PVC-160

63-160

SJSZ65/132

300

5m

100kw

24m

PVC-250

110-250

SJSZ80/156

400

3.5m

120kw

28m

PVC-315

160-315

SJSZ 80/156

400

3m

160kw

28m

PVC-450

250-450

SJSZ 92/188

700

1.5m

200kw

36m

PVC-630

315-630

SJSZ92/188

700

0.9

230kw

36m

3,Machine list1 set
PVC /UPVC pipe application
About PVC PIPE
PVC pipes (divided into PVC-U pipes, PVC-M pipes and PVC-O pipes) Rigid polyvinyl chloride pipes are made of polyvinyl chloride resin, stabilizers, lubricants, etc., and then extruded by hot pressing. The first plastic pipe to be developed and applied.

PVC-U pipe has strong corrosion resistance, easy bonding, low price, and hard texture. However, due to the seepage of PVC-U monomer and additives, it is only suitable for water supply systems whose conveying temperature does not exceed 45ºC. Plastic pipes are used for drainage, waste water, chemicals, heating and cooling fluids, food, ultra-pure liquids, mud, gas, compressed air and vacuum systems.

PVC-O pipe, Chinese name biaxially oriented polyvinyl chloride, is the latest evolutionary form of PVC pipe. The pipe manufactured through a special oriented processing process will use the extrusion method to produce the PVC-U pipe for axial stretching and diameter Stretching to make the long-chain PVC molecules in the pipe arranged biaxially, to obtain a new type of PVC pipe with high strength, high toughness, high impact resistance and fatigue resistance. Advantages of pipe

1. It has good tensile and compressive strength: but its flexibility is not as good as other plastic pipes.

2. Low fluid resistance: The wall of PVC-U pipe is very smooth and has little resistance to fluid. Its roughness coefficient is only 0.009. Its water delivery capacity is 20% higher than that of cast iron pipes of the same diameter and 40% higher than that of concrete pipe %.

3. Excellent corrosion resistance and chemical resistance: PVC-U pipes have excellent acid resistance, alkali resistance, and corrosion resistance, and are not affected by damp water and soil pH. No anti-corrosion treatment is required when laying pipes.

4. It has good water tightness: the installation of PVC-U pipes, whether by bonding or rubber ring connection, has good water tightness.

5. Anti-bite: PVC-U tube is not a source of nutrition, so it will not be corroded by rodents. According to a test conducted by the National Sanitation Foundation in Michigan, rats will not bite PVC-U pipes.

6. Performance test: curing time, shrinkage, splitting strength, tensile performance, peeling strength, thermal stability, pot life, storage period, release of harmful substances.About our company
