Pet Cup Lid Thermoforming Machine
BEHAPPY CRAFTS (SUZHOU) CO., LTD.Base Info
Description
Material
PS/PET/PVC (Hard Sheet)
Sheet Thickness
0.3-0.6mm
Sheet Width
450mm
Max Install Area Of Mould
450×300mm²
Max Forming Depth
45mm
Productivity
10-30 Strokes/min
Heating Rated Power
About 10kw/hour
Total Power
30Kw
Main Motor Power
3Kw
Power Supply
380V/50Hz(Three Phase Four Wire)
Voltage
0.6-0.8Mpa
Air Volume Required
2500~3500L/min
Water Volume Required
40~45L/min
Machine Weight
About 2200
Overall Dimension
3m×1m×1.8m
D.MORE PRODUCTS1.Plastic Sheet Extruder(Single Screw/Double Layers)
2.Plastic Thermoforming Machine(Cup/Lid/Bowl/Tray/Container Making Machine,etc...)
3.Thermoforming Moulds(Cup/Lid/Bowl/Tray/Container Mould,etc...)
4.Plastic Cup Printing Machine & Cup Packing Machine & Cup Stacking Machine
5.Film Blowing Machine & Flim Printing Machine & Bag Making Machine
6.Other Auxiliary Equipments:Mixing Machine,Material Feeding Machine,Cooling Tower,
Robot,Cup Stacking Machine,Hydraulic Forlift,Chiller,Crushing Machine,etc...
