Basic Info.

Model NO. FD-411A Max Output 10kg/Min(22lb/Min) Transport Package Fumigation-Free Plywood Specification CE approved Trademark Saijun Origin China HS Code 8477800000 Production Capacity 50 Sets/Month

Product Description

Item FD-411A Polyurethane foaming machine.
MOQ 1 set.
Delivery time Within 15 working days after T/T.

Standard configuration
Proportion Fixed Mainframe 1 set
Self-cleaning foaming gun 1 set
Feeding pump 2 sets
Heating hose 49.2 feet (15m)
Connecting hose from feeding pump to machine 10 feet(3m)
Connecting hose from heating hose to gun 5 feet(1.5m)
Rings and Tools

Technical Data
The ratio of raw material 1: 1(Fixed)
The viscosity range of raw material 200-1000CPS (Under the operate temperature)
Max working pressure 23 MPA (230 bar)
Max fluid temperature 88ºC (190ºF)
Max Output 10kg/min (22 lb/min)
Air motor diameter 6 inch
Heater power 3000W each one
Heating hose power 1000W/15m
Whole power 7500W
Voltage 230V 1-pH/400V 3-pH
Operate temperature 0ºC-70ºC
Clean mode Self-clean by air
Max heating hose length 295 feet (90m)
Pneumatic source 1MPA(10 bar, 145 psi)
Machine size 900mm*820mm*1150mm
1450mm*400mm*550mm
Gross weight 200KG
