Product Description

Overview:
CW700/1200A Automatic Computerized vacuum forming machine is designed by the principle of mechanical-electrical-pneumatic integration. It adopts PLC control system, panel and digital power control. This full-automatic forming equipment for thermoforming plastic sheet includes feeding, heating, forming, cooling, mold ejecting, cutting and one blow.
Application area:
This machine is mainly applied to plastic sheet material molding, such as EPS, HIPS, PVC, PET, PP and flocking sheet, etc. which produce all kinds of trays, trays for medicine injection, oral liquid, vegetables, telephones, cookies, tool, hardware, electron and disposable tableware, etc.

Product Parameters

Main technical parameters:Model:CW-700/1200A-1CW-700/1200A-2Forming length760-1200mm760-1200mmForming width500-700mm500-700mmForming height<165mm<165mmProduction speed60-720cycle/h60-720cycle/hElectro-thermal furnace power24kw24kw( upper)
18kw(lower)Vacuum motor power3kw3kwPumping rate100m³/h100m³/hAir compressor power7.5kw-11kw7.5kw-11kwAir displacement1.2m³/min1.2m³/minVoltage380/220V, 50Hz380/220V 50HzOverall dimensions7950×1450×2550mm7950×1450×2550mmWeight3000kg3500kg

ABOUT US

WORKSHOP
