Hot Sales Full Protective Exchange Platform Laser Cutting Machine
Dandong Dedan Trade Co., Ltd.- After-sales Service：Online Support
- Warranty：1 Years
- Application：Agriculture Machinery, Aerospace Industry, Automotive Industry
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Metal
Base Info
- Model NO.：1530
- Structure Type：Gantry Type
- Laser Classification：Gaseous Laser
- Laser Technology：Laser Flame Cutting
- Electrical Component：French Schneider
- Laser Head Brand：Raytools
- Laser Source Brand：Raycus
- Exchange Mode：Horizontal Exchange
- Max. Cutting Speed：120m,Min
- X/Y Positioning Accuracy：0.08mm
- X/Y Repeated Positioning Accuracy：0.02mm
- Transmission：Precise Rack and Pinion
- Transport Package：Wooden Box
- Specification：8700× 5000× 2300mm
- Trademark：HOSTON
- Origin：China
Description
Basic Info.
Model NO. 1530 Structure Type Gantry Type Laser Classification Gaseous Laser Laser Technology Laser Flame Cutting Electrical Component French Schneider Laser Head Brand Raytools Laser Source Brand Raycus Exchange Mode Horizontal Exchange Max. Cutting Speed 120m/Min X/Y Positioning Accuracy 0.08mm X/Y Repeated Positioning Accuracy 0.02mm Transmission Precise Rack and Pinion Transport Package Wooden Box Specification 8700× 5000× 2300mm Trademark HOSTON Origin ChinaProduct Description
| Model | 1530 | 2040 | 2060 | 2560 (6000W-8000W) | 2560 (10000W-2000W) | 2580 (6000W-8000W) | 2580 (10000W-2000W) | 25120 |
| Working Area (mm) | 1500×3000 | 2000×4000 | 2000×6000 | 2500×6000 | 2500×6000 | 2500×8000 | 2500×8000 | 2500×12000 |
| Machine Dimension (mm) | 8700×5000×2300 | 1100×5700×2300 | 15000×5700×2300 | 15400×4100×4900 | 15750×4380×5240 | 19800×4100×4900 | 20260×4380×5240 | 28600×7800×5200 |
| Exchange mode | Horizontal exchange | Horizontal exchange | Horizontal exchange | Horizontal exchange | Horizontal exchange | Horizontal exchange | Horizontal exchange | Horizontal exchange |
| Max. Cutting Speed (m/min) | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 |
| Max. Acceleration (G) | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 |
| X/Y Positioning Accuracy (mm) | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 |
| X/Y Repeated Positioning Accuracy (mm) | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 |
| Operating Voltage (V/Hz ) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Laser power (W) | 1500-20000 | 1500-20000 | 1500-20000 | 1500-20000 | 1500-20000 | 1500-20000 | 1500-20000 | 1500-20000 |
| Power consumption (KW) | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Machine Running Temperature (ºC) | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 |
| Machine Running Humidity | <90% | <90% | <90% | <90% | <90% | <90% | <90% | <90% |
| Transmission | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion |
