Drilling diameter

(mm)

150-250

Rotary spray pile diameter

(mm)

Drilling depth

(m)

130-200

Drill rod caliber/Tube diameter

(mm)

73, 89, 102, 114

Drill pipe inclination angle

(°)

0-90

Gyrator parameter

Rated output speed

(r/min)

10, 20, 30, 35, 40, 60, 65, 70, 85, 130, 170

Rated output torque

(N.m)

7500

Route

(mm)

3400

The route of shaft shackle slipping

(mm)

900

Lifting power

(kN)

70

Lifting speed

(m/min)

0-5(adjustable), 7, 23, 30

Pressure

(kN)

36

Pressure speed

(m/min)

0-10(adjustable), 14, 46, 59

Parameter of whole machine

Input power(electric motor)

(kW)

55+18.5

Overall dimension of main engine

Transport state(length*width*height)

(mm)

5400*2100*2000

Construction state(length*width*height)

(mm)

Weight of main engine

(kg)

6000

Walking parameter

Walking pattern

Crawler walking

Climbing angle

(°)

25

Crawler ground bearing

(kPa)

37.8

Traveling speed

(km/h)

0.4

Turning parameter

Turning way

Whole manual rotation

Turing structure

Pivotal bearing

Location mode

Locating pin

Auxiliary parts situation

Holder shackle device

Standard configuration

Crawler chassis

Standard configuration
