Rubber&Plastic Foam Flexible NBR Pipe Tube/Sheet/Board Machinery

Base Info

Description

 Conditions of UsePower3 phas,380V(-10%,+5%)50HzCompressed air0.4m3/min ,>0.5MPa Occupation acreageL 65 m W 4m H 3.5m         Part II  Equipment List
 Extrusion system

  1. Temperature Control System
            1. Hot air blower power
            5.5KW  X  37.5KW  X  2
            1.   Conveying device
            1. Transfer roller width
            1000mm 2 sets1200mm 2 sets1500mm 1 sets1700mm 1 sets
            1. Transfer motor power
            1.5KW X 8
            1.  speed control
            Asynchronous control
            1. quantity
            1unit/station
            1.  Tractor
            1. Effective traction length
            		4000 mm
            1. Effective traction width
            		1300 mm
            1. Main body
            		Rectangular pipe
            1. Roller shaft
            		304 stainless steel
            1. Roller distance
            		150 mm
            1. Transmission speed
            		0-25 m/min
            1. Conveying roller elevation
            		1000mm
            1. Forced air cooling
            		Axial Fan

            1. Sheet cutting machine
            1. Effective length
            		3000 mm
            1. Cutting width
            		1500 mm
            1. Cutting motor
            		1.5 kw
            1. Transmission speed
            		0-25m/min
            1. Center height
            		1000 min
            1. Electrical control
            PLC intelligent controlSiemens
            1. Electrical components
            		 Delixi
            1. speed control
            		Intelligent frequency conversion
            1. temperature control
            		Multi-point temperature control
            1. safety precaution
            		Multiple emergency stop buttons
