Automatic Bottle Blow Molding Machine (JMX70D) Made in China
Jinjiang Chaote Co., Ltd.Base Info
Description
ParametersSpecifications JMX70D Material HDPE Number of station 2 Number of die set 2L~4L/1die
1L~2L/2dies
0.5L~1L/3dies
0.2L~0.5L/4dies Dry cycle pc/hr 700x2 Machine Dimension(L×W×H) M 3.5x2.2x2.8 Total weight ton 7.1 Clamping Unit JMX70D Clamping force KN 105 Platen opening stroke mm 200--550 Platen size mm 500x550 Max. mould size (W×H) mm 550x500 Mould thickness mm 210-300 Power JMX70D Max. drive KW 27.5 Total power KW 48.5 Fan power for screw KW 0.54 Air pressure Mpa 0.7 Air consumption m³/min 0.6 Average energy consumption KW 18.5 Cooling water pressure Mpa 0.3 Water consumption L/min 70 Extruding unit JMX70D Screw diameter mm 70 Screw L/D ratio L/D 24 Plasticising capacity Kg/hr 75 Number of heating zone zone 4 Extruder heating power KW 12 Extruder driving power KW 22 Die JMX70D Number of heating zone zone 3--5 Power of die heating KW 6.6 Max. die-pin diameter mm 150 Central Distance of two die mm 150~200 Max.Die diameter(two die) mm 100 Central Distance of three die mm 110~140 Max.Die diameter(three die) mm 70 Central Distance of four die mm 70~100 Max.Die diameter(four die) mm 45
1L~2L/2dies
0.5L~1L/3dies
0.2L~0.5L/4dies
