High Quality Vertical Plastic Injection Molding Machines
JIANGSU VIKING HYDRAULIC & PURIFICATION TECHNOLOGY CO., LTD.Base Info
Description
JY-160S2/JY-200S2 Technique specification Model Units JY-160S2 JY-200S2
Injection System
Screw Diameter mm Φ26 Φ28 Φ28 Φ30 Injection Pressure Kg/cm2 1183 1019 1019 896 Theoretical Shot volume cm3 55.7 64.6 64.6 74 Max. Shot Weight(P.S) g/Oz 50/1.7 58/2.0 64.6/58 74/67 Injection Rate mm 105 105 Max.Screw speed rpm 0-215 0-200 Temperature Control ZONE 2 2
Clamping System
Clamping Force T 15 30 Platen Size mm 450*280 480*310 Distance Between Tie Bare mm 265 285 Min Mold Height mm 100/25 100/30 Opening Stroke mm 190 180 Max. Open Daylight mm 290/215 280/30 Ejector Force T 1.3 1.3 Ejector stroke mm 35 35
Hydraulic System
Max. Hydraulic Pressure Kg/cm2 140 140 Pump Output L 17.5 29.5 Pump Motor Power Kw 2.2/3HP 3.75/5HP Barrel Heating Power Kw 1.8 1.8 Total Wattage Kw 4.2 5.5
Others
Machine Dimensions (L*W*H) m 1.35*0.92*2.06 1.4*.90*2.37 Shipping Measurement (L*W*H) m 1.6*1.0*2.23 1.7*1.1*2.23 Machine Weight T 0.85 1.0 Shipping Weight T 1.0 1.3
Application :
Vertical injection machine have the advantage of low-noise, low-energy-consumption,high efficiency and long life time, it's widely apply to produce various terminal blocks, connectors, cables,auto parts, Plug ,etc.
Packing & Shipping :
1. Before shipping,we will check and test the machine carfully.
2. We will arrange to manufacture the second day after confirmation,we can delivery it usually after 25 days.
3. According to the destination,we will compare several transportation companies and select the most suitable and economic one to provide service for us
RFQ:
Q1: Are you a trading company or a manufactory?
A1: We own a factory ourselves, and we can assure the quality we manufactured.
Q2: What's your guarantee or the warranty of the quality if we buy your machines?
A2: We offer you high quality machines with high quality afterservice. Also we have one year
warranty of the spareparts, free of charge.
Q3: Why choose Jieyang Machinery Co.,Ltd.?
A3: Our products with more than 30% energy saving. Highest Cost effective environmentally. Excellent pre-sale and after-sale services.
