• Model NO.：TJX-1
• Raw Material：Potato
• Material：Stainless Steel
• Procedure：Automatic
• Capacity：200kg,H 500-1000kg,H
• Transport Package：Wooden Case
• Specification：780*520*730mm
• Trademark：DAYI
• Origin：Jinan China
• HS Code：84198100
• Production Capacity：50 Set, Month

   DEVICE NAME    INSTRODUCTION >Model:TSJ-5000*600
>Dimension:5000*1200*3000
>Power:1.5kw/380v/50hz
>Consist of: water tank+hoist device
>Material: SUS304
>Thickness: 3mm2. Brush washing machine
>Model: QXJ-2400
>Size: 3500*950*1900 mm
>Power: 4.55KW/380V/50HZ
>Spiral vane speed is adjustable
  Rolls speed is adjustable
>Filter to separate peel, sand from water
>Spraying device to wash during peeling
>Material: SUS304
>Shell: 1.5mm
  Board of the two sides: 10mm 3. Washing and Peeling machine>Model:QP J-2400
>Size: 3500*950*1670 mm
>Power: 4.55KW/380V/50HZ
>Spiral vane speed is adjustable
  Rolls speed is adjustable
>Filter to separate peel, sand from water
>Spraying device to wash during peeling
>Material: SUS304
>Shell: 1.5mm
  Board of the two sides: 10mm 4.Picking &inspecting lineIt has two function: one is picking line to pick ou
3 .All material is Stainless steel.
>Model: TJX-4000*600
>Size:4000*1400*1500
>Power: 1.1KW/380V/50HZ
>Two parts: returning device+picking line
>Material: SUS304 except the belt
  Material for belt: PVC P25-24
>Thickness: 2.5 mm
 5. Washing &Conveyor2It has three functions:
To wash off the sands and other dirt on potatoes in order to protect the cutter.
Convey it to cutter;
Distribute the fresh potato into two cutters
Mesh belt is board with holes.
>Model:TSJ-3800*600
>Dimension:3800*1200*3000
>Power:1.1kw/380v/50hz
>Consist of: water tank+hoist device
>Material: SUS304
>Thickness: 3 mm 6.Frecnh fries cutter
Easy to wash and easy to opSave labor and cost.
>Model:QTJ-1000
>Size: 1060*690*1040mm
>Power: 1.5kw 380V/50HZ/set
>Quantity: 2sets
>The normal size:8mm*8mm and 10*10mm and 6*6mm
 7. Bubble Washing machine
>Model: QXJ-3500*800
>Size: 3500*1800*2000mm
>Power: 8.03KW/380V/50HZ
>Function: hoisting device+redisue
 scraping device
>Material: SUS304
>Mesh belt frame thickness: 3 mm
  Body board thickness: 3mm
 8.Blanching machine 1


 the mesh belt is mesh with holes
>Model: PTJ1-6000*800
>Size: 6000*2000*2000mm
>Heating methord: Steam heating
>Power(gas): 10.78KW/380V/50HZ
>Material: SUS304
>Mesh belt frame thickness: 3 mm
  Body board thickness: 3mm9. Blanching machine 2  10. Vibrating dewatering and separating machine
The small residue will be removed by this machine
>Model: ZDS-2500*800
>Size:2500*1400*800
>Power: 0.37KW/380V/50HZ
>Material: SUS304
>Thickness: 2.5 mm
 11. 4m/3-long hot air drying line
>Model:FGX-4000*800/3
>Dimensions: 5000*1400*3000
>Power: 90KW/ 380V/ 60HZ
>Belt width:800mm
>Total length:12meter
>Material: SUS304
>mesh belt frame body: 3 mm 12. Continuous frying machine
>Model:XDL-4500×800.
>Dimesion:6000*2200*2200
>Capacity per hour: 200kg/h
>Principle: Continuous working
>Heating methord: thermal fluid heating system
>Material: SUS304
>mesh belt frame: 4mm
  Body: 4mm
  Control box: 1.5mm

 13. Vibrating machine1.It is used to remove some oil by vibrating
2. It is equipped with oil collection board and oil collection box
>Model: ZDS-2000*800
>Size:2000*1400*800
>Power: 0.37KW/380V/50HZ
>Material: SUS304
>Board thickness: 2.5 mm 14. 5m-3 layer cooling line>Model:FLX-5000*800/3
>Dimensions: 5000*1400*3000
>Power: 3.75KW/ 380V/ 50HZ
>Belt width:800mm
>Total length:15meter
>Material: SUS304
>frame thickness: 2.5 mm 15. vibrating machineIt is of 5mm holes;
>Model: ZDS-2500*1100
>Size:2500*1400*1150
>Length: 2.5m
>Belt width: 1100mm
>Power: 0.37KW/380V/60HZ
>Material: SUS304
>Thickness: 2.5 mm
 16. Packing machineThe parts included:
XD-620 Automatic packaging machine
14-heads combination weigher.
3.  bucket elevator
4. Supporting platform
5. Finished products conveyor
Packing machine
Packing speed: 10-60 bags/ min
Bag size: (W)100-300mm (L)100-380mm
Max film width: 220-620mm
Weigher:
Name: 14-hopper computer combination scale
 scale; SUS304 structure; 10.4 in
Hopper capacity:2500ml
Language:Chinese, English, Italy, Spanish, Franch, and 10 different languages
Display Screen:Color Display input keypad

Production Process:No.Product nameintroduction1Washing peeling machineWashing and peeling the potatoes; It is centrifugal washing peeling machine for small capacity; brush washing peeling for larger capacity2French fries cutterCut the potatoes into different sizes of French fries3Blanching machineWash and remove the potato powder and keep good color and flavor for the potato chips or French fries4Centrifugal dewater machineRemove water by the force of the centrifugal force5Frying machineFrying the French fries; oil or oil-water structure; electric, gas, diesel ; automatic feeding and discharging6Centrifugal deoil machineRemove the oil by the force of centrifugal7FreezerInstant freezer8Packing machinePack the French fries into different bags

The electric device are Siemens and other famous brand as following.

 NameBrandNoteFrequency converterOMRON Temperature controllerOMRON Converter contactorSCHNEIDER DisconnectorSIEMENS Switching push buttonSIEMENS
