Model()
 R-45-40/700   R-50-45/900  R-55-50/1200  R-65-55/1400Width of the film
()200-600mm   250-800mm  500-1100mm 500-1300mmThickness of the film()0.006-0.15mmThe max output()85kg/h   125kg/h 150kg/h  175kg/h
According to different width,thickness of film, die size and raw material characteristics to change
(,,)Raw material()HDPE/LDPE/LDPEPower consumption()25kw/h   28kw/h  35kw/h  40kw/hWeight()2800kg   3200kg  3800kg  4200kgOverall dimension(L*W*H)m
(**)6.5*2.7*5  6.5*3*5.8 6.5*3.8*6.2   6.8*4*6.8Extruder unit()Diameter of screw
()Φ45/50  Φ50/45   Φ55/50   Φ65/55
38CrMoALA  wearproof Alloy steel,five years guaranteeL/D ratio of screw
()30:1Rotation speed of screw
()10-120r/mBarrel Fan
()Zone 3 barrels install over-temperature fan
(3)Gear box()146#×2   173#×2   200#×2   225#×2
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation system
(,,)Main motor()11kw    15kw   30kw   37kw
100% Original three-phase variable frequency motor  Equipped with inverter control
(100%   )Die head unit()Die diameter
()50mm   60mm  80mm   250mm  360mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effect
(40Cr,8,,)Cool unit()Air ring type
()LDPE double vents vacuum air ring(HDPE)
HDPESingle outlet air ring(HDPE )Air ring material
()High quality Taiwan cast aluminum alloy air ring
()Bellow power
()1.5kw  4kw   2.2kw   7.5kw   Shanghai production of high-pressure mute fan
()Traction unit()Width of take up roller
()700mm  900mm   1200mm   1400mmTraction roller material
()silicone roll()
NBR roller()Take up motor
()1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter control
(RV  )Take up speed
()100m/min
 1.5kw10N.m
 700mm  900mm   1200mm   1400mmEmbossing roller
()hot embossing unit (   )
cold embossing unit()Lambdoidal board
()Wooden flannel wrapped()
Aluminum roller guide  ( )
 Gusset equipment
()Modular rack type    ()
Independent Split  ()Bubble stabilizing ring
()Electric aluminum roller guide  ( )
Manual wood floor ()Guide roller()Aluminum guide roller (HV300-HV700) surface treatment
( (HV300-HV700))Winding unit()Winding type
()Surface friction rewinding, manually change the volume
(,)Drive type()Torque motor equipped RV reducer(RV)Film expanding roller()Smoothing roll()
The second traction part,
Independent torque control constand tension controlElectric control cabinet()low-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control table
(,,,)Computer control type()7-inch touch screen + process control system(7+)
Automatic air supply device ()


 Service

Our Advantage:
1.      First-class and professional service team offer one-stop intimate service. 18 senior technical experts, more than 20 after sales service staff.
2.     No charge for training the technician, let you have nothing to worry about!
3.     Five yearafter-sales service and mechanical parts lifetime warranty.
4.     Life-long free for offering all kinds of technical service and 24 hours after service.(no worry about the time differences)

Order step
     step1. Please let us know which product you like. the model and size, the offers will be sent to you within 24 hours.
     step2.  We make proforma invoice (PI) for you.
     step3. Please check and confirm the PI
     step4. Once we confirmed the order, please pay it soon.
     step5. After payment, all goods will be sent to you in the delivery time.
