• Model NO.：KLD- flake fish feed plant
• Model：Kld- Flake Fish Feed Plant
• Condition：New
• Raw Material：Bone Powder, Corn Powder and So on
• Worker Needed：2- 4 Workers
• Moter：Siemens, ABB and Other China Brand
• Energy：Electric, Gas, Dissel
• Warranty：1 Year After Commissioning
• After- Sale Services：Overseas Engineers
• Machine Material：Stainless Steel
• Capacity：40- 600 Kg, H
• Transport Package：Plastic Bag and Wooden Case
• Specification：Fully stainless steel
• Trademark：KLD
• Origin：Shandong, China
• HS Code：843800000
• Production Capacity：10- 100 Kg,H

Basic Info.

Model NO. KLD- flake fish feed plant Model Kld- Flake Fish Feed Plant Condition New Raw Material Bone Powder, Corn Powder and So on Worker Needed 2- 4 Workers Moter Siemens, ABB and Other China Brand Energy Electric/ Gas/ Dissel Warranty 1 Year After Commissioning After- Sale Services Overseas Engineers Machine Material Stainless Steel Capacity 40- 600 Kg/ H Transport Package Plastic Bag and Wooden Case Specification Fully stainless steel Trademark KLD Origin Shandong, China HS Code 843800000 Production Capacity 10- 100 Kg/H

Product Description

1. Product description
A. Brief introduction for flake fish feed plant
      flake fish feed plant is a kind of rotating continuous drying equipment with internal heating conducting style. Certain thickness of materials film attached to the drum from material liquid vessel under the drum. Heat is transferred to the interal wall of the cylinder through pipes and then to the external wall and to the external wall and to materials. Dried products are then scraped off by the blade fitted on the serface of the cylinder, fall down to the sprial conveyorunder the blade, and are conveyed, collected and packed.

B. Features of flake fish feed plant
1).Large operation elasticity and wide application. Various drying factors of the dryer can be adjusted, such as concentration of feeding liquid/ thickness of materials film, temperature of heating medium, roating speed of the drum ext which can change drying speed of the under dryer. As these factors have no interrelations each other, it brings great convenience to dry opeartion and makes it applicable to dry various materials and to meed different requirements of production.
2).Short drying period. The drying period materials is normally 10 to 300 seconds, so it is suitable for heatsensitive materials. It also can be pressure reducing operated if it is put in vaccum vessel.
3)Fast drying rate. As film of materials coated on the wall of cylinder is very thin. Normal, thichness is 0.3 to 1.5mm, plus direction of heat and mass transmitting are indentical, the evaporation strength on the surface of the film can be 20-70Kg water per square meter in one hour.

2. Machine Parameter of flake fish feed plant

Model	Drying capacity(kg·H2O/m²·h)	Steam consumption(kg/h)	Power(kw)	Dimension(mm)	Weight(kg)
KLD600	40- 70	100- 175	2.3	1700*800*1500	850
KLD700	60- 90	150- 225	3	2100*1000*1800	1210
KLD800	90- 130	225- 325	4	2500*1100*1980	1700
KLD1000	130- 190	325- 475	5.5	2700*1300*2250	2100
KLD1200	160- 250	400- 625	7.5	2800*1500*2450	2650
KLD1400	210- 310	525- 775	11	3150*1700*2800	3220
KLD1600	270- 400	675- 1000	11	3350*1900*3150	4350
KLD1800	330- 500	825- 1250	15	3600*2050*3500	5100
KLD1800A	420- 630	1050- 1575	18.5	4100*2050*3500	6150

3. Service for the flake fish feed plant
1). We make accurate factory layout design according to customer's factory size; if the customer needed, we could make workshop design.
2). After receiving firm order and down payment, we start to apply for the Visa to your country immediately; while the machines arrives your factory, our engineers are ready to start for the commissioning service.
3). 1-2 of our engineers will go to your factory to install and adjust the processing line to realize normal production at shortest time.
4). Our engineers have responsibility to teach the workers how to operate, clean, maintain and repair all the machines, until the workers could well operate the processing line.
5). Our engineers can provide basic formula for the production, and help the customer to produce good quality food according customer's detailed formula
6). It normally costs 10-14 days for the commissioning service, and we supply 1 year guarantee from the date of completion of commissioning service.

4. Packing&Delivery for flake fish feed plant
Packing:
Inside:Plastic bag for the flake fish feed plant.
Ouside:Wooden case (adopt the wooden case or wooden pellets depended on clients' requirement).
Transportation:
Shipping, train, express, or upon clients' demands.

5. Clients With Us
We have through the years established good working relationships with some reputable organizations both at home and abroad with outstanding goodwill.Our clients will have a good trip and happy coorperating experience with us, jinan kelid machinery co., ltd

6. About Us
   Jinan Kelid Machinery Co., Ltd. Is a professional supplier of food processing machines.Our company's motto is:"technology makes easy".We offer to cooperate with our customers for mutual and beneficial development.
   We have through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill.Our main products line include food extrusion machine, soya meal/meat processing machines, industrial micro wave oven,  packaging machines, rice cake machine etc.Most importantly, we also provide formulas, technology supports, machine inspection service, etc.
