CSD-AB SERIES TWO-STAGE AUTOMATIC LINEAR HIGH-SPEED BLOW MOLDING MACHINEItemUnitCSD-AB2-2LCSD-AB3-1.25LCSD-AB4-2LCSD-AB5-1.25LCSD-AB6-1.5LCSD-AB2-5LCSD-AB2-10LCavity 2345622Product Volume                                                 L≤2L≤1.25L≤2L≤1.25L≤1.5L5L≤10LProduction
capacity                                                  Max. Capacity
(500ml water bottle)
28-30mmPcs/h3130Pcs/h
(2.3s/cycle)4500Pcs/h
(2.4s/cycle)6000Pcs/h
(2.4s/cycle)7200Pcs/h
(2.5s/cycle)8000Pcs/h
(2.7s/cycle) 900Pcs/h
(4s/cycle)Recommended
Production Capacity Pcs/h2800-3000Pcs/h
Based on 500ML water bottle,
Preform Neck 28-30mm,
Weight:17gram,
Thickness:2.3mm

2000-2250Pcs/h
Based on 1500ML water bottle,
Preform Neck 2830mm,
Weight:42gram,
Thickness:3.3mm4000-4200Pcs/h
Based on 500ML water bottle,
Preform Neck 28-30mm,
Weight:17gram,
Thickness:2.3mm

3100-3500Pcs/h
Based on 1000ML water bottle,
Preform Neck 28-30mm,
Weight:28gram,
Thickness:3mm5000-5500Pcs/h
Based on 500ML water bottle,
Preform Neck 28-30mm,
Weight:17gram,
Thickness:2.3mm

4100-4500Pcs/h
Based on 1500ML water bottle,
Preform Neck 28-30mm,
Weight:42gram,
Thickness:3.3mm6200-6660Pcs/h
Based on 500ML water bottle,
Preform Neck 28-30mm,
Weight:17gram,
Thickness:2.3mm

5000-5500Pcs/h
Based on 1000ML water bottle,
 Preform Neck 28-30mm, Weight:28gram,
Thickness:3mm6600-7000Pcs/h
Based on 500ML water bottle,
Preform Neck 28-30mm,
Weight:17gram,
Thickness:2.3mm

5000-5500Pcs/h
Based on 1500ML water bottle,
Preform Neck 28-30mm, Weight:42gram,
Thickness:3.3mm1600-1700Pcs/h
Based on 5L bottle,
Preform Neck 45mm,
Weight:60gram,
Thickness:3.3mm1100-1200Pcs/h
Based on 10L bottle,
Preform Neck 45mm,
Weight:200gram,

 Max Diameter of ProductΦ(mm)120901209095160200Neck Size of ProductΦ(mm)15-3815-3815-3815-3815-3838-4535-45Useful Area of Mould Platemm350×350350×350520×350520×350880×400480×400620×460Max.Mould Thicknessmm220220220220258230300Min.Mould Thicknessmm180180180180250Mould Strokemm158110158110116220240Clamping ForceKn120120210210300300300Stretching Strokemm350350350350350350500Working PressureMpa0.8-1.00.8-1.00.8-1.00.8-1.00.8-1.00.8-1.00.8-1.0Blowing Air PressureMpa2.6-3.02.6-3.02.6-3.02.6-3.02.6-3.02.6-3.02.6-3.0Measurement of Main BlowerL×W×H(mm)3000×1850×19003100×1850×19004400×2000×19004400×2000×19007000×1750×19004450×2000×19005000×2000×1900Power of Preheaterkw4848969611098122A7272144144165102183Power of Main Blowerkw5558855Weight of Main BlowerT4455755Measurement of ConveyerL×W×H(mm)2570×2570×27002570×2570×27002890×2570×27002890×2570×27003600×2500×35002500×2000×27502500×2000×2750Weight of ConveyerT0.20.20.20.20.40.20.2High Pressure
Air Compressor Unit Powerkw22×222×222×322×322×422×422×4PressureMpa3.0 3.0 3.0 3.0 3.0 3.0 3.0 Discharging Capa.m³/min44668810Low Pressure
Air Compressor Unit Powerkw22222230442230PressureMpa1.251.251.251.251.251.251.25Discharging  Capa.m³/min3.0 3.0 3.0 4.0 6.0 3.0 4.0 Air TankCapacitym³0.60.60.61222Working PressureMpa3.0 3.0 3.0 3.0 3.0 3.0 3.0 Water ChillerCooling Capacitykcal/hr35200352003520049800498003520035200Compressor MotorHP10101515151010Air DryerCapacitym³/min44668810Working PressureMpa3.0 3.0 3.0 3.0 3.0 3.0 3.0 After CoolerCapacitym³/min44668810Working PressureMpa3.0 3.0 3.0 3.0 3.0 3.0 3.0 Air Filter
Oil Filter
Odor Removal FilterCapacitym³/min44668810Working PressureMpa3.0 3.0 3.0 3.0 3.0 3.0 3.0
