| MD-ASY(YT) series printing and film blowing machine |
| Main Technical Parameters |
| Model :MD- | ASY(YT)50 | ASY(YT)55 | ASY(YT)60 | |
| Suitable Material | HDPE/LDPE/LLDPE | |
| Max Film Width(mm) | 600 | 800 | 1000 | |
| Film Thickness(mm) | HD:0.008-0.08 | |
| LD:0.02-0.15 | |
| Max Extrusion Output HD | 40kg/hr | 50kg/hr | 60kg/hr | |
| LD | 50kg/hr | 60kg/hr | 70kg/hr | |
| Extrusion unit |
| Gear Box | 146 | 173 | 173 | |
| Screw Diameter(mm) | φ50 | φ55 | φ60 | |
| Screw L/D Ratio | 28:1 | 28:1 | 28:1 | |
| Screw's Material | 38 CRMOALA | |
| Barrel's Material | 38 CRMOALA | |
| Barrel's Cooling Fan | 250W×2 | 370W×2 | 370×2 | |
| Thermo Control (zone) | 3 | 3 | 3 | |
| Driving Motor (kw) | 11 | 18.5 | 22 | |
| Extrusion Die |
| Die Size (mm) | HD:φ60 | HD:φ80 | HD:φ100 | |
| LD:φ150 | LD:φ180 | LD:φ220 | |
| Screen Changer | Standard manual | |
| Thermo Control (zone) | 2 | 2 | 2 | |
| Air Ring (mm) | φ620 | φ760 | φ760 | |
| Cooling Blower (kw) | 1.5 | 2.2 | 2.2 | |
| Center Steady Stick | 1 PCS | |
| Take-UP Unit |
| Roller Width (mm) | φ138×650 | φ138×850 | φ138×1100 | |
| Take-UP Motor (kw) | 0.75 | 1.1 | 1.1 | |
| Take-UP Speed(M/min) | 10-60 | 10-60 | 10-60 | |
| Height adjustable type | 700mm | |
| Winding Unit |
| Type OF Winder | Surface Friction Winder | |
| Roller Width (mm) | 700 | 900 | 1100 | |
| Winding Motor (N.M) | 6 | 10 | 10 | |
| Winding Speed(M/min) | 10-60 | 10-60 | 10-60 | |
| Printing Length(mm) | 190-960mm | |
| Max Printing Width(mm) | 560 | 760 | 960 | |
| Voltage | 380V, 50HZ, 3PHASE | |
| Cover Dimensions (m) | 7×2.0×4.3 | 7×2.2×4.5 | 7.5×2.5×4.8 | |
| | | | | |
OPTIONAL EQUIPMENT | | | |
| 1)AUTO LOADER | | | |
| 2)CORONA( | | | |
| 3)AIR SHAFT | | | | |
| 4)MANUAL MECHANICS SCREEN CHANGER | | |
| 5)DIE ROTARY DEVICE | | | |
| 6)AUTOMATICALLY SUPPLY AIR | | |
