Danfoss Dh Series Hydraulic Orbit Motor
Guangzhou Cospack Packaging Technology Co., Ltd.- Certification：CE, ISO9001
- Type：Hydraulic Motor
- Code：Oz36,50,80,100,125,160,200,250,315,400
- Output Shaft：25mm, 25.4mm Straight Shaft and Cone Shaft
- Flange：2 Holes Rhomb-Flange
- Motor of Material：Cast Iron
Base Info
- Model NO.：DH
- Omh Motor Key：Parallel Key, Spline Key
- Fuel：Hydraulic Oil
- Hydraulic Valve：Proportional Control Valve
- Auxiliary Components：Seal
- Hydraulic Power Units：Vane Pump
- Hydraulic Motor：Orbit Hydraulic Motor Oz
- Transport Package：Sale Packing: Plastic Film and Carton or Wood
- Specification：CE
- Trademark：Blince
- Origin：Guangdong, China (Mainland)
- HS Code：8412291000
- Production Capacity：100000 PCS,Year
Description
Max.torque
(N.m)Max.output
(kw) Max pressure
(MPa) Max.oil
Flow(L/min)
cont. cont. int. cont. int. cont. int. cont. OZ36 37 1081 51 68 5.2 8.6 10.5 14 40 OZ50 51.7 774 73 96 5.2 8.6 10.5 14 40 OZ80 77.7 515 106 143 5.2 8.6 10.5 14 40 OZ100 96.2 416 140 178 5.2 8.6 10.5 14 40 OZ125 117.9 339 162 218 5.2 8.6 10.5 14 40 OZ160 155.5 257 216 288 5.2 8.6 10.5 14 40 OZ200 189.9 211 264 351 5.2 8.6 10.5 14 40 OZ250 231 173 281 351 4.6 7 9 11.5 40 OZ315 311.7 128 312 433 3.4 5.8 7 10.5 40 OZ400 386.2 104 392 582 3.4 5.8 7 10.5 40
(N.m)
(kw)
(MPa)
Flow(L/min)
