• Model NO.：CKD-CMLA-20,30,50,60,70
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Function：Mark, Engrave, Cut
• Material：Marking, Engraving and Cutting
• Warranty：2 Years for Laser Source, 1 Year for Others
• Computer：Optional, with Marking Software, English Language
• Shipping Date：3-5 Work Days After Payment
• Marking Speed：Optional:1-2000,1-4000,1-7000
• Laser Power：Optional: 20,30,50,60,70W
• Transport Package：Wooden Box
• Specification：CE passed, Europe, Asia, America Standard
• Trademark：CKD LASER
• Origin：Shenzhen, China
• HS Code：8486204900
• Production Capacity：200 Sets,Month

laser source30W/40/70Optional marking scope recommendCKD-CMLA-30/40100*100mmbig marking scope weaken laser power, there are suitable recommend for you.CKD-CMLA-70Optional: 100*100/150*150/200*200mmComputerWindow 7/10Computer language: English as basic, you can choose your language after receiving. Marking SoftwareEzCad2Language: English, Chinese, Korean, Japanese Control BoardBJJCZOriginal newest version Rotarychuck diameter: 50mmOptional part, for jewelry markingOptionalchuck diameter: 80mmOptional part, for tuber or column markingchuck diameter: 100mmOptional part, for bigger column, cup, bottle, etc.Foot switchwithstandard attchment, every type with Focusing toolwith help you find right focus easily, standard attchment, every type with
PARAMETER

Parameters	Unit	Data	Data
Type		CKD-CMLA-30/40	CKD-CMLA-70
Power	W	30/40	70
Laser Type		CO2 laser	CO2 Laser
Central Wavelength	um	10.6	10.6
Optional Marking Area	mm	75*75/140*140	75*75/140*140/175*175/210*210
Marking Speed	mm/s	≤7000	≤7000
Software		EzCad	EzCad
Life-span of Fiber Laser Module	hrs	45000	45000
System Operation Environment		Windows 7/8/10	Windows 7/8/10
Cooling Mode		Air cooling	Air cooling
Temperature of Operation Environment	ºC	15~35	15~35
Power Source Requirement		90-240V/50-60Hz/2KVA	90-240V/50-60Hz/2KVA
Computer		With	With
Dimension (L*W*H)	mm	980*615*1480	980*615*1480

ADVANTAGE
* Multi-functions: carving/engraving/marking/cutting.
* Series number jumping mark, photo amrk, vector logo mark, etc.
* Anti-interference, stability.
* High accuracy, long time use without correction.
* Compact structure, all-in-one machine, easy lean and operation.
