PVC Pipe Processing Line
Linyi Kunhong Tools Co., Ltd.Base Info
Description
SPECIFICATIONS FOR PVC PIPE EXTRUSION LINEModel Pipe spec(mm) Conical twin screw extruder Max.output
(kg/h) Total power(kw) GWG63-PVC Φ20-Φ63 GSZ65/132 180-300 104 GWG160-PVC Φ63-Φ160 GSZ65/132 180-300 105 GWG250-PVC Φ75-Φ250 GSZ80/156 300-450 110 GWG315-PVC Φ200-Φ315 GSZ80/156 300-450 216 GWG450-PVC Φ200-Φ450 GSZ92/188 650-750 290 GWG630-PVC Φ315-Φ630 GSZ92/188 750-850 350 GWG800-PVC Φ500-Φ800 GSZ135/31 950-1100 410 Model Motor power(kw) Screw diameter
(mm) Max.speed
(rpm) L/D Max.capacity(kg/h) Weight(kg) GSP75/28 37 75 36 28:1 280 4100 GSP93/13 45/55 93 45 31:1 450 4700 GSP110/31 90/110 110 45 31:1 680 6500 GSP120/31 110/132 120 45 31:1 850 7500 GSP135/31 160 135 45 31:1 1100 8400
The list of pvc pipe extrusion line:
Main feature:
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Running in a high automatization and intellectualization,no pollution
4) Apply a linker to connect with the screw loader ,which can directly inline with filling machine .
(kg/h)
(mm)
(rpm)
The list of pvc pipe extrusion line:
| NO. | Equipment | Qty. | Remark |
| 1 | GSZ65/132 conical Twin-Screw Extruder | 1 set | 22KW |
| 2 | Mould(including heater and calibrator) | 1set | |
| 3 | Dual Vacuum Tank | 1 set | |
| 4 | Dual Haul-off unit | 1set | |
| 5 | guilotine type Cutter | 1set | |
| 6 | Stacker | 1set | |
| 7 | Electric Control System | 1set | |
| 8 | Spare Parts | 1set |
Main feature:
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Running in a high automatization and intellectualization,no pollution
4) Apply a linker to connect with the screw loader ,which can directly inline with filling machine .
