• Model NO.：FD200
• Material：Stainless 304
• Capacity：50-200kg,H
• Transport Package：Wooden Case
• Specification：ce. iso
• Trademark：shinwei
• Origin：Shanghai
• HS Code：84382000
• Production Capacity：50-200kg

Basic Info.

Model NO. FD200 Material Stainless 304 Capacity 50-200kg/H Transport Package Wooden Case Specification ce. iso Trademark shinwei Origin Shanghai HS Code 84382000 Production Capacity 50-200kg

Product Description

FD100/200 Fondant Beating Machine
Features:

The machine is mainly used for making fondant masses, it is simple to use fondant-beating machine. Sugar, glucose, water is dissolved then put into the hopper of the fondant beater. The beater is turned on and the cooked syrup is fed into the creaming screw. The sugar syrup is then agitated in a controlled way to seed the syrup into a fine fondant paste. The machine has a capacity of 75kg per hour and is ideal for a entry level machine. The unit has heated hopper and a jacketed barrel for cooling.

Main Technical Specifications:


Model	FD100	FD200
Output(kg/h)	Up to 100kg/h	Up to 200kg/h
Motor Power	4kW/380V/50HZ	5.5kW/380V/50HZ
Heating power	2kW/380V/50HZ	4kW/380V/50HZ
Cooling water Temp.	12C	12C
Water consumption	1000L/h	1600L/h
Machine dimensions	1950x800x1500mm	1950x800x1800mm
Weight of the machine	800kg	1400kg
