• Model NO.：KQ
• Mixer：Follow Your Request
• Working Life：More Than 10years
• Tank Function：Heating, Fermenting, Mixing , Warm Keeping
• Voltage：Follow Your Request
• CIP：CIP Cleaning Tank
• Level Meter：Yes
• Spare Parts：Available
• MOQ：1set
• OEM：Yes
• Transport Package：Standard Export Wooden Box
• Specification：ISO
• Trademark：KQ
• Origin：Shanghai China
• HS Code：8479820090
• Production Capacity：100sets Per Month

Basic Info.

Model NO. KQ Mixer Follow Your Request Working Life More Than 10years Tank Function Heating, Fermenting, Mixing , Warm Keeping Voltage Follow Your Request CIP CIP Cleaning Tank Level Meter Yes Spare Parts Available MOQ 1set OEM Yes Transport Package Standard Export Wooden Box Specification ISO Trademark KQ Origin Shanghai China HS Code 8479820090 Production Capacity 100sets Per Month

Product Description

                                                 1000L 3000L 5000L Milk PorrIdge Soup Paste Cereal Mix Tank





Shanghai Kaiquan Machine Valves Co.ltd offers the broadest range of tank heating solutions in the electric heatingindustry. .... jacketed vessel application is the heating of chocolate
ELECTRIC HEATING MILK BATCH PASTEURIZER

TankCapacity(L)	200, SS304	300, SS304	500, SS304	1000,SS304
REV	36r/min	36r/min	36r/min	36r/min
Electric motor of the agitator	0.55KW,380v,50hz	0.75KW,380v,50hz	0.75KW,380v,50hz	1.1KW,380v,50hz
Electric heating tube power	15KW,380v,50hz	18KW,380v,50hz	24KW,380v,50hz	45KW,380v,50hz
Heating Area(M2)	0.9	1.1	1.9	4.5
Material Input/output(DN MM)	38	38	38	50
OUTSIDE DEMENSION(L*W*H)MM	900*900*1600	1000*1000*1500	1100*1100*1700	1400*1400*1750
GROSS WEIGHT(KGS)	150	200	300	450

Other specifications can make to your order .
 Accessories:
(1)Lid able to open on the top
(2) Charging/discharging hole at the bottom,
(3) Heat transfer oils (water) Inlet/outlet,
(4) Temperature probe,
(5) CIP cleaning ball,
(6) Heating tube, (7) Electric cabinet, (8) Reduction gears, (9) Rack & blender etc. (10)The electric motor(2.2KW, 380V, 50Hz)
 Yogurt Pasteurizer Sterilizer Sterilization Tank
1000L 3000L 5000L Milk PorrIdge Soup Paste Cereal Mix Tank  .
