Tysim Kr300ds Hydraulic Low Head Room Piling Pile Driver with Max. Depth 26m and Diameter 2000mm
Hefei Huiwo Digital Control Equipment Co., Ltd.Base Info
Description
Technical specification of KR330DS rotary drilling rigTorque 320 kN.m Max. diameter 2000 mm Max. drilling depth 26m Speed of rotation 6~26 rpm Max. crowd pressure 220 kN Max. crowd pull 230 kN Main winch line pull 230 kN Main winch line speed 80m/min Auxiliary winch line pull 110 kN Auxiliary winch line speed 75m/min Stroke(crowd system) 2000mm Mast inclination(lateral) ±5° Mast inclination(forward) 5° Max. operating pressure 35 MPa Pilot pressure 3.9 MPa Travel speed 1.5 km/h Traction force 550 kN Operating height 11087 mm Operating width 4300mm Transport height 3590 mm Transport width 3000 mm Transport length 10651 mm Overall weight 76 t
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is 1 year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
