Model

HWDR150D

Dimensions

8700mm*2300mm*3200mm

Wheelbase

3250mm

Wheel-track

1600mm/Front, 1260mm/Rear

Vehicle weight

9000(KG)

Engine power

120-150HP

Piling depth

1-15(m)

Drilling diameter

400-2200(mm)

Swing angle

180°

Walking speed

50(km/h)

Working pressure of hydraulic system

20-30(Mpa)

Hydraulic system displacement

80ml/r


We also produce other depth. for square kellybar and machine lock lever bar, Max depth 30m.

15 m wheel rotary excavator / Small rotary excavator rotation 180 degree
